APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-119
0x3353 Max.Openings 1 hour F004 1 R/W 1 [1 , 60]
0x3354 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3367 Confirmation address W 1
Ajustes Contadores Interruptor - Breaker Maintenance Settings
0x3368 KI2t BKR Ph A Cnt F003 1 R/W 2 [0.00 , 9999.99] (KA)2 s
0x336A KI2t BKR Ph B Cnt F003 1 R/W 2 [0.00 , 9999.99] (KA)2 s
0x336C KI2t BKR Ph C Cnt F003 1 R/W 2 [0.00 , 9999.99] (KA)2 s
0x336E BKR Openings Cnt F004 1 R/W 1 [0 , 9999]
0x336F BKR Closings Cnt F004 1 R/W 1 [0 , 9999]
0x3383 Confirmation address W 1
Ajustes Mapa Usuario Modbus - Modbus User Map Settings
0x3384 Address 00 F004 1 R/W 1 [0 , 65535]
0x3385 Address 01 F004 1 R/W 1
[0 , 65535]
... ... ... ... ... ... ... ...
0x3483 Address 255 F004 1 R/W 1 [0 , 65535]
0x3494 Confirmation address W 1
Ajustes Curva Usuario A - Flex Curves A Settings
0x3495 Time 0.00xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x3497 Time 0.05xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x3499 Time 0.10xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x349B Time 0.15xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x349D Time 0.20xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x349F Time 0.25xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34A1 Time 0.30xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34A3 Time 0.35xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34A5 Time 0.40xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34A7 Time 0.45xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34A9 Time 0.48xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34AB Time 0.50xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34AD Time 0.52xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34AF Time 0.54xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34B1 Time 0.56xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34B3 Time 0.58xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34B5 Time 0.60xPKP [RST] F003 1
R/W 2 [0.000 , 65.535] s
0x34B7 Time 0.62xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34B9 Time 0.64xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34BB Time 0.66xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34BD Time 0.68xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34BF Time 0.70xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34C1 Time 0.72xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34C3 Time 0.74xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34C5 Time 0.76xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34C7 Time 0.78xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34C9 Time 0.80xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34CB Time 0.82xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34CD Time 0.84xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34CF Time 0.86xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34D1 Time 0.88xPKP [RST] F003 1 R/W 2 [0.000 , 65.535] s
0x34D3 Time 0.90xPKP [RST] F003 1 R/W 2
[0.000 , 65.535] s
