APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-129
0x3877 Time 14.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3879 Time 14.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x387B Time 15.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x387D Time 15.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x387F Time 16.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3881 Time 16.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3883 Time 17.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3885 Time 17.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3887 Time 18.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x3889 Time 18.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x388B Time 19.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x388D Time 19.50xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x388F Time 20.00xPKP [OP] F003 1 R/W 2 [0.000 , 65.535] s
0x38A4 Confirmation address W 1
Ajustes Protocolo Modbus - MODBUS Settings
0x38A5 Modbus Address COM1 F004 1 R/W 1 [1 , 255]
0x38A6 Modbus Address COM2 F004 1 R/W 1 [1 , 255]
0x38A7 Modbus Port Number F005 1 R/W 2 [0 , 65535]
0x38BC Confirmation address W 1
Ajustes Puertos Serie - SERIAL PORTS Settings
0x38BD COM1 Baud Rate F012 1 R/W 1 0=300
1=600
2=1200
3=2400
4=4800
5=9600
6=19200
7=38400
8=57600
9=115200
0x38BE COM2 Baud Rate F012 1 R/W 1 0=300
1=600
2=1200
3=2400
4=4800
5=9600
6=19200
7=38400
8=57600
9=115200
0x38BF COM1 Parity F012 1000 R/W 1 0=NONE
1=ODD
2=EVEN
0x38C0 COM2 Parity F012 1000 R/W 1 0=NONE
1=ODD
2=EVEN
0x38D3 Confirmation address W 1
Ajustes Registrador de Datos - Data Logger Settings
0x38D4 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
