B-130 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x38D5 Data Logger Rate F012 1 R/W 1 0=1 s
1=5 Minutes
2=10 Minutes
3=15 Minutes
4=20 Minutes
5=30 Minutes
6=60 Minutes
0x38D6 Data Logger Chnl 1 F004 1 R/W 1 [0 , 32767]
0x38D7 Data Logger Chnl 2 F004 1 R/W 1 [0 , 32767]
0x38D8 Data Logger Chnl 3 F004 1 R/W 1 [0 , 32767]
0x38D9 Data Logger Chnl 4 F004 1 R/W 1 [0 , 32767]
0x38DA Data Logger Chnl 5 F004 1 R/W 1 [0 , 32767]
0x38DB Data Logger Chnl 6 F004 1 R/W 1 [0 , 32767]
0x38DC Data Logger Chnl 7 F004 1 R/W 1 [0 , 32767]
0x38DD Data Logger Chnl 8 F004 1 R/W 1 [0 , 32767]
0x38DE Data Logger Chnl 9 F004 1 R/W 1 [0 , 32767]
0x38DF Data Logger Chnl 10 F004 1
R/W 1 [0 , 32767]
0x38E0 Data Logger Chnl 11 F004 1 R/W 1 [0 , 32767]
0x38E1 Data Logger Chnl 12 F004 1 R/W 1 [0 , 32767]
0x38E2 Data Logger Chnl 13 F004 1 R/W 1 [0 , 32767]
0x38E3 Data Logger Chnl 14 F004 1 R/W 1 [0 , 32767]
0x38E4 Data Logger Chnl 15 F004 1 R/W 1 [0 , 32767]
0x38E5 Data Logger Chnl 16 F004 1 R/W 1 [0 , 32767]
0x38F9 Confirmation address W 1
Ajustes unidad direccional de potencia Grupo 1 - Directional Power 1 Settings
0x38FA Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x38FB Blk Time After Close F003 1 R/W 2
[0,00 , 900,00] s
0x38FD Dir Power Angle 1 F003 1 R/W 2 [0,00 , 359,99] Deg
0x38FF Stage 1 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x3901 Stage 1 Time F003 1 R/W 2 [0,00 , 900,00] s
0x3903 Dir Power Angle 2 F003 1 R/W 2 [0,00 , 359,99] Deg
0x3905 Stage 2 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x3907 Stage 2 Time F003 1 R/W 2 [0,00 , 900,00] s
0x3909 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x391C Confirmation address W 1
Ajustes unidad direccional de potencia Grupo 2 - Directional Power 2 Settings
0x391D Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x391E Blk Time After Close F003 1 R/W 2 [0,00 , 900,00] s
0x3920 Dir Power Angle 1 F003 1 R/W 2 [0,00 , 359,99] Deg
0x3922 Stage 1 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x3924 Stage 1 Time F003 1 R/W 2 [0,00 , 900,00] s
0x3926 Dir Power Angle 2 F003 1 R/W 2 [0,00 , 359,99] Deg
0x3928 Stage 2 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x392A Stage 2 Time F003 1 R/W 2 [0,00 , 900,00] s
0x392C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x393F Confirmation address W 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
