APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-131
Ajustes unidad direccional de potencia Grupo 3 - Directional Power 3 Settings
0x3940 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3941 Blk Time After Close F003 1 R/W 2 [0,00 , 900,00] s
0x3943 Dir Power Angle 1 F003 1 R/W 2 [0,00 , 359,99] Deg
0x3945 Stage 1 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x3947 Stage 1 Time F003 1 R/W 2 [0,00 , 900,00] s
0x3949 Dir Power Angle 2 F003 1 R/W 2 [0,00 , 359,99] Deg
0x394B Stage 2 Tap F003 1 R/W 2 [-10000,00 , 10000,00] MW
0x394D Stage 2 Time F003 1 R/W 2 [0,00 , 900,00] s
0x394F Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3962 Confirmation address W 1
Ajustes unidad Rotor Bloqueado Grupo 1 - Locked Rotor 1 Settings
Locked Rotor 1
0x3963 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3964 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x3965 Full Load Current F003 1 R/W 2 [0.10 , 10.00] KA
0x3967 Pickup Level F003 1 R/W 2 [1.01 , 109.00]
0x3969 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x396B Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x396D Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3977 Confirmation address W 1
Ajustes unidad Rotor Bloqueado Grupo 2 - Locked Rotor 2 Settings
Locked Rotor 2
0x3978 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x3979 Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x397A Full Load Current F003 1 R/W 2 [0.10 , 10.00] KA
0x397C Pickup Level F003 1 R/W 2 [1.01 , 109.00]
0x397E Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x3980 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x3982 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x398C Confirmation address W 1
Ajustes unidad Rotor Bloqueado Grupo 3 - Locked Rotor 3 Settings
Locked Rotor 3
0x398D Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x398E Input F012 1 R/W 1 0=PHASOR(DFT)
1=RMS
0x398F Full Load Current F003 1 R/W 2 [0.10 , 10.00] KA
0x3991 Pickup Level F003 1 R/W 2 [1.01 , 109.00]
0x3993 Trip Delay F003 1 R/W 2 [0.00 , 900.00] s
0x3995 Reset Delay F003 1 R/W 2 [0.00 , 900.00] s
0x3997 Snapshot Events F012 1 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
