B-132 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
1=ENABLED
0x39A1 Confirmation address W 1
Ajustes Comunicaciones Remotas - Remote Communications Settings
0x3A76 Remote Comms F012 1 R/W 1 0=DISABLED
1=GSSE
2=GOOSE
0x3A77 F650 ID F009 1 R/W 33
0x3A98 Hold Time F005 1 R/W 2 [1000 , 60000] ms
0x3A9A Events Remote Out F012 1 R/W 1 0=DISABLED
1=ENABLED
Ajustes Entradas Remotas (32 elementos) - Remote Inputs Settings (32 items) [Only Configurable for GSSE]
0x3A9B Remote Device 1 F009 1 R/W 33
0x3ABC Bit Pair 1 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
34=UserSt-2
--------
96=UserSt-64
0x3ABD Default Value 1 F012 1 R/W 1 0=OFF
1=ON
2=Latest OFF
3=Latest ON
Ajustes Entradas Remotas (32 elementos) - Remote Inputs Settings (32 items) [Only Configurable for GSSE](cont.)
0x3ABE Remote Device 2 F009 1 R/W 33
0x3ADF Bit Pair 2 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
34=UserSt-2
--------
96=UserSt-64
0x3AE0 Default Value 2 F012 1 R/W 1 0=OFF
1=ON
2=Latest OFF
3=Latest ON
... ... ... ... ... ... ... ...
... ... ... ... ... ... ... ...
... ... ... ... ... ... ... ...
0x3ED8 Remote Device 32 F009 1 R/W 33
0x3EF9 Bit Pair 32 F012 1 R/W 1 0=NONE
1=DNA-1
2=DNA-2
--------
32=DNA-32
33=UserSt-1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
