APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP

GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-133

34=UserSt-2

--------

96=UserSt-64

0x3EFA Default Value 32 F012 1 R/W 1 0=OFF

1=ON

2=Latest OFF

3=Latest ON

0x3EFB Events Remote Inp F012 1 R/W 1 0=DISABLED

1=ENABLED

0x3EFC Destination MAC Data1 F004 1000 R/W 1

0x3EFD Destination MAC Data2 F004 1000 R/W 1

0x3EFE Destination MAC Data3 F004 1000 R/W 1

0x3EFF GSSE RemDevice01 MAC Data1 F004 1000 R/W 1

0x3F00 GSSE RemDevice01 MAC Data2 F004 1000 R/W 1

0x3F01 GSSE RemDevice01 MAC Data3 F004 1000 R/W 1

0x3F02 GSSE RemDevice02 MAC Data1 F004 1000 R/W 1

0x3F03 GSSE RemDevice02 MAC Data2 F004 1000 R/W 1

0x3F04 GSSE RemDevice02 MAC Data3 F004 1000 R/W 1

0x3F05 GSSE RemDevice03 MAC Data1 F004 1000 R/W 1

0x3F06 GSSE RemDevice03 MAC Data2 F004 1000 R/W 1

0x3F07 GSSE RemDevice03 MAC Data3 F004 1000 R/W 1

0x3F08 GSSE RemDevice04 MAC Data1 F004

1000 R/W 1

0x3F09 GSSE RemDevice04 MAC Data2 F004 1000 R/W 1

0x3F0A GSSE RemDevice04 MAC Data3 F004 1000 R/W 1

0x3F0B GSSE RemDevice05 MAC Data1 F004 1000 R/W 1

0x3F0C GSSE RemDevice05 MAC Data2 F004 1000 R/W 1

0x3F0D GSSE RemDevice05 MAC Data3 F004 1000 R/W 1

0x3F0E GSSE RemDevice06 MAC Data1 F004 1000 R/W 1

0x3F0F GSSE RemDevice06 MAC Data2 F004 1000 R/W 1

0x3F10 GSSE RemDevice06 MAC Data3 F004 1000 R/W 1

0x3F11 GSSE RemDevice07 MAC Data1 F004 1000 R/W 1

0x3F12 GSSE RemDevice07 MAC Data2 F004 1000 R/W 1

0x3F13 GSSE RemDevice07 MAC Data3 F004 1000 R/W 1

0x3F14 GSSE RemDevice08 MAC Data1 F004 1000 R/W 1

0x3F15 GSSE RemDevice08 MAC Data2 F004 1000 R/W 1

0x3F16 GSSE RemDevice08 MAC Data3 F004 1000 R/W 1

0x3F17 GSSE RemDevice09 MAC Data1 F004 1000 R/W 1

0x3F18 GSSE RemDevice09 MAC Data2 F004 1000 R/W 1

0x3F19 GSSE RemDevice09 MAC Data3 F004 1000 R/W 1

0x3F1A GSSE RemDevice10 MAC Data1 F004 1000 R/W 1

0x3F1B GSSE RemDevice10 MAC Data2 F004 1000 R/W 1

0x3F1C GSSE RemDevice10 MAC Data3 F004 1000 R/W 1

0x3F1D GSSE RemDevice11 MAC Data1 F004 1000 R/W 1

0x3F1E GSSE RemDevice11 MAC Data2 F004 1000 R/W

1

0x3F1F GSSE RemDevice11 MAC Data3 F004 1000 R/W 1

0x3F20 GSSE RemDevice12 MAC Data1 F004 1000 R/W 1

0x3F21 GSSE RemDevice12 MAC Data2 F004 1000 R/W 1

0x3F22 GSSE RemDevice12 MAC Data3 F004 1000 R/W 1

0x3F23 GSSE RemDevice13 MAC Data1 F004 1000 R/W 1

ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
