APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-135
0x3F62 Server IP Oct 4 F004 1 R/W 1 [0 , 255]
0x3F66 Confirmation address
0x3F67 Server2 UDP Port F004 1 R/W 1 [0 , 255]
0x3F69 Server2 IP Oct 1 F004 1 R/W 1 [0 , 255]
0x3F6A Server2 IP Oct 2 F004 1 R/W 1 [0 , 255]
0x3F6B Server2 IP Oct 3 F004 1 R/W 1 [0 , 255]
0x3F6C Server2 IP Oct 4 F004 1 R/W 1 [0 , 255]
0x3F87 Confirmation address W 1
Contador de Pulsos-Pulse Counters
0x3F88 PulseCntr Enabled 1 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x3F89 PulseCntr Name 1 F009 1,000 R/W 16
0x3F99 PulseCntr Factor 1 F003 1,000 R/W 2 [0.000 , 65000.000]
0x3F9B PulseCntr Overflow 1 F005 1,000 R/W 2 [0 , 1000000]
0x3F9D PulseCntr Board Origin 1 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x3F9E PulseCntr Input Origin 1 F004 1,000 R/W 1 [1 , 32]
0x3F9F PulseCntr Enabled 2 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x3FA0 PulseCntr Name 2 F009 1,000 R/W 16
0x3FB0 PulseCntr Factor 2 F003 1,000 R/W 2 [0.000 , 65000.000]
0x3FB2 PulseCntr Overflow 2 F005 1,000 R/W 2 [0 , 1000000]
0x3FB4 PulseCntr Board Origin 2 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x3FB5 PulseCntr Input Origin 2 F004 1,000 R/W 1 [1 , 32]
0x3FB6 PulseCntr Enabled 3 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x3FB7 PulseCntr Name 3 F009 1,000 R/W 16
0x3FC7 PulseCntr Factor 3 F003 1,000 R/W 2 [0.000 , 65000.000]
0x3FC9 PulseCntr Overflow 3 F005 1,000 R/W 2 [0 , 1000000]
0x3FCB PulseCntr Board Origin 3 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x3FCC PulseCntr Input Origin 3 F004 1,000 R/W
1 [1 , 32]
0x3FCD PulseCntr Enabled 4 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x3FCE PulseCntr Name 4 F009 1,000 R/W 16
0x3FDE PulseCntr Factor 4 F003 1,000 R/W 2
[0.000 , 65000.000]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
