B-136 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x3FE0 PulseCntr Overflow 4 F005 1,000 R/W 2 [0 , 1000000]
0x3FE2 PulseCntr Board Origin 4 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x3FE3 PulseCntr Input Origin 4 F004 1,000 R/W 1 [1 , 32]
0x3FE4 PulseCntr Enabled 5 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
Contador de Pulsos-Pulse Counters(cont.)
0x3FE5 PulseCntr Name 5 F009 1,000 R/W 16
0x3FF5 PulseCntr Factor 5 F003 1,000 R/W 2 [0.000 , 65000.000]
0x3FF7 PulseCntr Overflow 5 F005 1,000 R/W 2 [0 , 1000000]
0x3FF9 PulseCntr Board Origin 5 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x3FFA PulseCntr Input Origin 5 F004 1,000 R/W 1 [1 , 32]
0x3FFB PulseCntr Enabled 6 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x3FFC PulseCntr Name 6 F009 1,000 R/W 16
0x400C PulseCntr Factor 6 F003 1,000 R/W 2 [0.000 , 65000.000]
0x400E PulseCntr Overflow 6 F005 1,000 R/W 2 [0 , 1000000]
0x4010 PulseCntr Board Origin 6 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x4011 PulseCntr Input Origin 6 F004 1,000 R/W 1 [1 , 32]
0x4012 PulseCntr Enabled 7 F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x4013 PulseCntr Name 7 F009 1,000 R/W 16
0x4023 PulseCntr Factor 7 F003 1,000 R/W 2 [0.000 , 65000.000]
0x4025 PulseCntr Overflow 7 F005 1,000 R/W 2 [0 , 1000000]
0x4027 PulseCntr Board Origin 7 F012 1,000 R/W 1 0=F
1=G
2=H
3=J
0x4028 PulseCntr Input Origin 7 F004 1,000 R/W 1 [1 , 32]
0x4029 PulseCntr Enabled 8 F012 1,000 R/W 1
0=DISABLED
1=ENABLED
0x402A PulseCntr Name 8 F009 1,000 R/W 16
0x403A PulseCntr Factor 8 F003 1,000 R/W 2 [0.000 , 65000.000]
0x403C PulseCntr Overflow 8 F005 1,000 R/W 2
[0 , 1000000]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
