B-138 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x4082 Analog Delay 05 F003 1,000 R/W 2 [0.00 , 900.00] s
0x4084 Analog Hysteresis 05 F003 1,000 R/W 2 [0.0 , 50.0]
0x4086 Analog Direction 05 F012 1,000 R/W 1 0=OUT
1=IN
0x4087 Analog Input 06 F004 1,000 R/W 1
0x4088 Analog Maximum 06 F003 1,000 R/W 2
[-100000.000 , 100000.000]
Comparadores Analógicos-Analog comparators(cont.)
0x408A Analog Minimum 06 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x408C Analog Delay 06 F003 1,000 R/W 2 [0.00 , 900.00] s
0x408E Analog Hysteresis 06 F003 1,000 R/W 2 [0.0 , 50.0]
0x4090 Analog Direction 06 F012 1,000 R/W 1 0=OUT
1=IN
0x4091 Analog Input 07 F004 1,000 R/W 1
0x4092 Analog Maximum 07 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4094 Analog Minimum 07 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4096 Analog Delay 07 F003 1,000 R/W 2 [0.00 , 900.00] s
0x4098 Analog Hysteresis 07 F003 1,000 R/W 2 [0.0 , 50.0]
0x409A Analog Direction 07 F012 1,000 R/W 1 0=OUT
1=IN
0x409B Analog Input 08 F004 1,000 R/W 1
0x409C Analog Maximum 08 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x409E Analog Minimum 08 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40A0 Analog Delay 08 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40A2 Analog Hysteresis 08 F003 1,000 R/W 2 [0.0 , 50.0]
0x40A4 Analog Direction 08 F012 1,000 R/W 1 0=OUT
1=IN
0x40A5 Analog Input 09 F004 1,000 R/W 1
0x40A6 Analog Maximum 09 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40A8 Analog Minimum 09 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40AA Analog Delay 09 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40AC Analog Hysteresis 09 F003 1,000 R/W 2 [0.0 , 50.0]
0x40AE Analog Direction 09 F012 1,000 R/W 1 0=OUT
1=IN
0x40AF Analog Input 10 F004 1,000 R/W 1
0x40B0 Analog Maximum 10 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40B2 Analog Minimum 10 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40B4 Analog Delay 10 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40B6 Analog Hysteresis 10 F003 1,000 R/W 2 [0.0 , 50.0]
0x40B8 Analog Direction 10 F012 1,000 R/W 1 0=OUT
1=IN
0x40B9 Analog Input 11 F004 1,000 R/W 1
0x40BA Analog Maximum 11 F003 1,000 R/W 2
[-100000.000 , 100000.000]
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
