APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-139
0x40BC Analog Minimum 11 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40BE Analog Delay 11 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40C0 Analog Hysteresis 11 F003 1,000 R/W 2 [0.0 , 50.0]
0x40C2 Analog Direction 11 F012 1,000 R/W 1 0=OUT
1=IN
0x40C3 Analog Input 12 F004 1,000 R/W 1
Comparadores Analógicos-Analog comparators(cont.)
0x40C4 Analog Maximum 12 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40C6 Analog Minimum 12 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40C8 Analog Delay 12 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40CA Analog Hysteresis 12 F003 1,000 R/W 2 [0.0 , 50.0]
0x40CC Analog Direction 12 F012 1,000 R/W 1 0=OUT
1=IN
0x40CD Analog Input 13 F004 1,000 R/W 1
0x40CE Analog Maximum 13 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40D0 Analog Minimum 13 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40D2 Analog Delay 13 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40D4 Analog Hysteresis 13 F003 1,000 R/W 2 [0.0 , 50.0]
0x40D6 Analog Direction 13 F012 1,000 R/W 1 0=OUT
1=IN
0x40D7 Analog Input 14 F004 1,000 R/W 1
0x40D8 Analog Maximum 14 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40DA Analog Minimum 14 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40DC Analog Delay 14 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40DE Analog Hysteresis 14 F003 1,000 R/W 2 [0.0 , 50.0]
0x40E0 Analog Direction 14 F012 1,000 R/W 1 0=OUT
1=IN
0x40E1 Analog Input 15 F004 1,000 R/W 1
0x40E2 Analog Maximum 15 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40E4 Analog Minimum 15 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40E6 Analog Delay 15 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40E8 Analog Hysteresis 15 F003 1,000 R/W 2 [0.0 , 50.0]
0x40EA Analog Direction 15 F012 1,000 R/W 1 0=OUT
1=IN
0x40EB Analog Input 16 F004 1,000 R/W 1
0x40EC Analog Maximum 16 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40EE Analog Minimum 16 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40F0 Analog Delay 16 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40F2 Analog Hysteresis 16 F003 1,000 R/W 2 [0.0 , 50.0]
0x40F4 Analog Direction 16 F012 1,000 R/W 1 0=OUT
1=IN
0x40F5 Analog Input 17 F004 1,000 R/W 1
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
