B-140 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x40F6 Analog Maximum 17 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40F8 Analog Minimum 17 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x40FA Analog Delay 17 F003 1,000 R/W 2 [0.00 , 900.00] s
0x40FC Analog Hysteresis 17 F003 1,000 R/W 2 [0.0 , 50.0]
0x40FE Analog Direction 17 F012 1,000 R/W 1 0=OUT
1=IN
Comparadores Analógicos-Analog comparators(cont.)
0x40FF Analog Input 18 F004 1,000 R/W 1
0x4100 Analog Maximum 18 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4102 Analog Minimum 18 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4104 Analog Delay 18 F003 1,000 R/W 2 [0.00 , 900.00] s
0x4106 Analog Hysteresis 18 F003 1,000 R/W 2 [0.0 , 50.0]
0x4108 Analog Direction 18 F012 1,000 R/W 1 0=OUT
1=IN
0x4109 Analog Input 19 F004 1,000 R/W 1
0x410A Analog Maximum 19 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x410C Analog Minimum 19 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x410E Analog Delay 19 F003 1,000 R/W 2 [0.00 , 900.00] s
0x4110 Analog Hysteresis 19 F003 1,000 R/W 2 [0.0 , 50.0]
0x4112 Analog Direction 19 F012 1,000 R/W 1 0=OUT
1=IN
0x4113 Analog Input 20 F004 1,000 R/W 1
0x4114 Analog Maximum 20 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4116 Analog Minimum 20 F003 1,000 R/W 2 [-100000.000 , 100000.000]
0x4118 Analog Delay 20 F003 1,000 R/W 2 [0.00 , 900.00] s
0x411A Analog Hysteresis 20 F003 1,000 R/W 2 [0.0 , 50.0]
0x411C Analog Direction 20 F012 1,000 R/W 1 0=OUT
1=IN
0x412F Confirmation address W 1
Ajustes Derivada de Frecuencia 1-Frequency Rate of Change 1 Settings
0x4130 Function F012 1,000 R/W 1 0=DISABLED
1=ENABLED
0x4131 Freq. Rate Trend F012 1,000 R/W 1 0=INCREASING
1=DECREASING
2=BI-DIRECTIONAL
0x4132 Freq. Rate Pickup F003 1,000 R/W 2 [0.10 , 10.00] Hz/s
0x4134 Freq. Rate OV Supv F003 1,000 R/W 2 [0.00 , 110.00] %
0x4136 Freq. Rate Min F003 1,000 R/W 2 [20.00 , 80.00] Hz
0x4138 Freq. Rate Max F003 1,000 R/W 2 [20.00 , 80.00] Hz
0x413A Freq. Rate Delay F003 1,000 R/W 2 [0.00 , 60.00] s
0x413C Snapshot Events F012 1,000 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
