APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-147
1=ENABLED
0x48E3 DigCnt 3 Name F009 1000 R/W 16
0x48F3 DigCnt 3 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48F5 DigCnt 3 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48F7 DigCnt 4 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x48F8 DigCnt 4 Name F009 1000 R/W 16
0x4908 DigCnt 4 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x490A DigCnt 4 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x490C DigCnt 5 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x490D DigCnt 5 Name F009 1000 R/W 16
0x491D DigCnt 5 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x491F DigCnt 5 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x4921 DigCnt 6 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4922 DigCnt 6 Name F009 1000 R/W 16
0x4932 DigCnt 6 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x4934 DigCnt 6 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x4936 DigCnt 7 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4937 DigCnt 7 Name F009 1000 R/W 16
0x4947 DigCnt 7 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x4949 DigCnt 7 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x494B DigCnt 8 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x494C DigCnt 8 Name F009 1000 R/W 16
0x495C DigCnt 8 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x495E DigCnt 8 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x4960 Snapshot Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x496A Confirmation address W 1
PTP 1588
0x4975 PTP FUNCTION F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4976 PORTA DELAY ADDER F005 1000 R/W 2 [0 , 60000] ns
0x4978 PORTA DELAY ASYM F004 1000 R/W 1 [-1000 , 1000] ns
0x497A PORTB DELAY ADDER F005 1000 R/W 2 [0 , 60000] ns
0x497C PORTB DELAY ASYM F004 1000 R/W 1 [-1000 , 1000] ns
0x497D STRICT POWER PROFILE F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x497E PTP DOMAIN NUMBER F004 1000 R/W 1 [0 , 255]
0x497F PTP VLAN PRIORITY F004 1000 R/W 1 [0 , 7]
0x4980 PTP VLAN ID F004 1000 R/W 1 [0 , 4095]
0x4981 PTP EPOCH F012 1000 R/W 1 0=UTC_SINCE_2000
1=UTC_SINCE_1900
2=UTC_SINCE_1970
0x4988 Confirmation address W 1
Routing
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
