B-146 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
1=Second
2=Third
3=Fourth
4=Last
0x4555 DST START HOUR F004 1 R/W 1 [0 , 23]
0x4556 DST STOP MONTH F012 1 R/W 1 0=JAN
1=FEB
2=MAR
3=APR
4=MAY
5=JUN
6=JUL
7=AUG
8=SEP
9=OCT
10=NOV
11=DEC
0x4557 DST STOP WEEKDAY F012 1 R/W 1 0=Monday
1=Tuesday
2=Wednesday
3=Thursday
4=Friday
5=Saturday
6=Sunday
0x4558 DST STOP DAY INST F012 1 R/W 1 0=First
1=Second
2=Third
3=Fourth
4=Last
Ajustes de Fecha y Hora - Time Settings (cont.)
0x4559 DST STOP HOUR F004 1 R/W 1 [0 , 23]
0x455A IRIG-B LOCAL TIME F012 1 R/W 1 0=OFF
1=ON
0x455B IRIGB Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x455C PTP IRIGB Priority F012 1000 R/W 1 0=PTP-1588
1=IRIG-B
0x4564 Confirmation address W 1
Digital Counters
0x48B8 DigCnt 1 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x48B9 DigCnt 1 Name F009 1000 R/W 16
0x48C9 DigCnt 1 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48CB DigCnt 1 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48CD DigCnt 2 Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x48CE DigCnt 2 Name F009 1000 R/W 16
0x48DE DigCnt 2 Preset F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48E0 DigCnt 2 Compare F005 1000 R/W 2 [-2147483648 , 2147483647]
0x48E2 DigCnt 3 Function F012 1000 R/W 1
0=DISABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
