APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-145
0x4527 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x4528 Voltage Pickup Level F003 1 R/W 2 [2.00 , 70.00] V
0x452A Current Selection F012 1 R/W 1 0=IN
1=IG
0x452B OC Pickup Level F003 1 R/W 2 [0.005 , 0.400] A
0x452D OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x452F Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x4531 MTA F004 1 R/W 1 [0 , 360] Deg
0x4532 Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x4534 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
2=USER CURVE A
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x4535 Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x4537 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x4541 Confirmation address W 1
Ajustes IEC 870-5-103 - IEC 870-5-103 Settings
0x4542 COMM Port F012 1 R/W 1 0=NONE
1=COM 1
0x4543 Slave Number F004 1 R/W 1 [0 , 254]
0x4544 Synchronization Timeout F004 1 R/W 1 [0 , 1440] min
0x454E Confirmation address W 1
Ajustes de Fecha y Hora - Time Settings
0x454F LOC TIME OFFS. UTC F003 1 R/W 2 [-24.0 , 24.0]
0x4551 DAYLIG. SAVINGS TIME F012 1 R/W 1 0=DISABLED
1=ENABLED
0x4552 DST START MONTH F012 1 R/W 1 0=JAN
1=FEB
2=MAR
3=APR
4=MAY
5=JUN
6=JUL
7=AUG
8=SEP
9=OCT
10=NOV
11=DEC
0x4553 DST START WEEKDAY F012 1 R/W 1 0=Monday
1=Tuesday
2=Wednesday
3=Thursday
4=Friday
5=Saturday
6=Sunday
0x4554 DST START DAY INST F012 1 R/W 1
0=First
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
