B-144 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x44E4 Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x44E6 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44F0 Confirmation address W 1
32N1 Low - wattmetric Ground Fault Low Level Group 1 Settings
0x44F1 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44F2 Voltage Pickup Level F003 1 R/W 2 [2.00 , 70.00] V
0x44F4 Current Selection F012 1 R/W 1 0=IN
1=IG
0x44F5 OC Pickup Level F003 1 R/W 2 [0.005 , 0.400] A
0x44F7 OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44F9 Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x44FB MTA F004 1 R/W 1 [0 , 360] Deg
0x44FC Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44FE Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
2=USER CURVE A
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x44FF Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x4501 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x450B Confirmation address W 1
32N2 Low - wattmetric Ground Fault Low Level Group 2 Settings
0x450C Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x450D Voltage Pickup Level F003 1 R/W 2 [2.00 , 70.00] V
0x450F Current Selection F012 1 R/W 1 0=IN
1=IG
0x4510 OC Pickup Level F003 1 R/W 2 [0.005 , 0.400] A
0x4512 OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x4514 Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x4516 MTA F004 1 R/W 1 [0 , 360] Deg
0x4517 Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x4519 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
2=USER CURVE A
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x451A Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x451C Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x4526 Confirmation address W 1
32N3 Low - wattmetric Ground Fault Low Level Group 3 Settings
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
