APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-143
0x44A6 OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44A8 Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x44AA MTA F004 1 R/W 1 [0 , 360] Deg
0x44AB Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44AD Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
2=USER CURVE A
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x44AE Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x44B0 Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44BA Confirmation address W 1
32N2 High - wattmetric Ground Fault High Level Group 2 Settings
0x44BB Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44BC Voltage Pickup Level F003 1 R/W 2 [2.00 , 70.00] V
0x44BE Current Selection F012 1 R/W 1 0=IN
1=IG
0x44BF OC Pickup Level F003 1 R/W 2 [0.005 , 0.400] A
0x44C1 OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44C3 Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x44C5 MTA F004 1 R/W 1 [0 , 360] Deg
0x44C6 Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44C8 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
32N2 High - wattmetric Ground Fault High Level Group 2 Settings(cont.)
2=USER CURVE A
3=USER CURVE B
4=USER CURVE C
5=USER CURVE D
0x44C9 Multiplier F003 1 R/W 2 [0.02 , 2.00] s
0x44CB Snapshot Events F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44D5 Confirmation address W 1
32N3 High - wattmetric Ground Fault High Level Group 3 Settings
0x44D6 Function F012 1 R/W 1 0=DISABLED
1=ENABLED
0x44D7 Voltage Pickup Level F003 1 R/W 2 [2.00 , 70.00] V
0x44D9 Current Selection F012 1 R/W 1 0=IN
1=IG
0x44DA OC Pickup Level F003 1 R/W 2 [0.005 , 0.400] A
0x44DC OC Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44DE Power Pickup F003 1 R/W 2 [0.01 , 4.50] W
0x44E0 MTA F004 1 R/W 1 [0 , 360] Deg
0x44E1 Power Pickup Delay F003 1 R/W 2 [0.00 , 600.00] s
0x44E3 Curve F012 1 R/W 1 0=DEFINITE TIME
1=INVERSE TIME
2=USER CURVE A
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
