APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-149
0x49BA Static RT4 GWY Oct2 F004 1000 R/W 1 [0 , 255]
0x49BB Static RT4 GWY Oct3 F004 1000 R/W 1 [0 , 255]
0x49BC Static RT4 GWY Oct4 F004 1000 R/W 1 [0 , 255]
0x49BD Static RT5 IP Oct1 F004 1000 R/W 1 [0 , 255]
0x49BE Static RT5 IP Oct2 F004 1000 R/W 1 [0 , 255]
0x49BF Static RT5 IP Oct3 F004 1000 R/W 1 [0 , 255]
0x49C0 Static RT5 IP Oct4 F004 1000 R/W 1 [0 , 255]
0x49C1 Static RT5 Mask Oct1 F004 1000 R/W 1 [0 , 255]
0x49C2 Static RT5 Mask Oct2 F004 1000 R/W 1 [0 , 255]
0x49C3 Static RT5 Mask Oct3 F004 1000 R/W 1 [0 , 255]
0x49C4 Static RT5 Mask Oct4 F004 1000 R/W 1 [0 , 255]
0x49C5 Static RT5 GWY Oct1 F004 1000 R/W 1 [0 , 255]
0x49C6 Static RT5 GWY Oct2 F004 1000 R/W 1 [0 , 255]
0x49C7 Static RT5 GWY Oct3 F004 1000 R/W 1 [0 , 255]
0x49C8 Static RT5 GWY Oct4 F004 1000 R/W 1 [0 , 255]
0x49C9 Static RT6 IP Oct1 F004 1000 R/W 1 [0 , 255]
0x49CA Static RT6 IP Oct2 F004 1000 R/W 1 [0 , 255]
0x49CB Static RT6 IP Oct3 F004 1000 R/W 1 [0 , 255]
0x49CC Static RT6 IP Oct4 F004 1000 R/W 1 [0 , 255]
0x49CD Static RT6 Mask Oct1 F004 1000 R/W 1 [0 , 255]
0x49CE Static RT6 Mask Oct2 F004 1000 R/W 1 [0 , 255]
0x49CF Static RT6 Mask Oct3 F004 1000 R/W 1 [0 , 255]
0x49D0 Static RT6 Mask Oct4 F004 1000 R/W 1 [0 , 255]
0x49D1 Static RT6 GWY Oct1 F004 1000 R/W 1 [0 , 255]
0x49D2 Static RT6 GWY Oct2 F004 1000 R/W 1 [0 , 255]
0x49D3 Static RT6 GWY Oct3 F004 1000 R/W 1 [0 , 255]
0x49D4 Static RT6 GWY Oct4 F004 1000 R/W 1 [0 , 255]
0x49EC Confirmation address W 1
Network(Ethernet) E Settings
0x49ED IP Address Oct1 F004 1000 R/W 1 [0 , 255]
0x49EE IP Address Oct2 F004 1000 R/W 1 [0 , 255]
0x49EF IP Address Oct3 F004 1000 R/W 1 [0 , 255]
0x49F0 IP Address Oct4 F004 1000 R/W 1 [0 , 255]
0x49F1 Netmask Oct1 F004 1000 R/W 1 [0 , 255]
0x49F2 Netmask Oct2 F004 1000 R/W 1 [0 , 255]
0x49F3 Netmask Oct3 F004 1000 R/W 1 [0 , 255]
0x49F4 Netmask Oct4 F004 1000 R/W 1 [0 , 255]
0x4A05 Confirmation address W 1
Redundancy settings
0x4A06 REDUNDANCY MODE F012 1000 R/W 1 0=INDEPENDENT
1=LLA
2=PRP
3=HSR
4=RSTP
5=DAISY_CHAIN
0x4A07 LLA Priority F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4A08 LLA Timeout F005 1000 R/W 2
[0 , 600000] ms
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
