B-150 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x4A0A RSTP BRIDGE PRIORITY F005 1000 R/W 2 [0 , 61440]
0x4A0C RSTP PORTA PRIORITY F005 1000 R/W 2 [0 , 240]
0x4A0E RSTP PORTA PATHCOST F005 1000 R/W 2 [0 , 2000000]
0x4A10 RSTP PORTB PRIORITY F005 1000 R/W 2 [0 , 240]
0x4A12 RSTP PORTB PATHCOST F005 1000 R/W 2 [0 , 2000000]
0x4A1E Confirmation address W 1
Cold Load Pickup
0x4A1F Cold Load Function F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4A20 Cold Outage Time F004 1000 R/W 1 [1 , 1000] min
0x4A21 Cold Blocking Time F004 1000 R/W 1 [1 , 1000] s
0x4A22 Cold Load Events F012 1000 R/W 1 0=DISABLED
1=ENABLED
0x4A28 Confirmation address W 1
Ajustes de unidad de Sobrefrequencia Grupo 4- Overfrequency 4 Settings
0x39DD Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x39DE Pickup Level F003 1.000 R/W 2 [20
0x39E0 Trip Delay F003 1.000 R/W 2 [0
0x39E2 Reset Delay F003 1.000 R/W 2 [0
0x39E4 Minimum Voltage F003 1.000 R/W 2 [10
0x39E6 Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x39E7 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x39F9 Confirmation address W 1
Ajustes de unidad Subfrencuencia Grupo4- Underfrequency 4 Settings
0x39FA Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x39FB Pickup Level F003 1.000 R/W 2 [20
0x39FD Trip Delay F003 1.000 R/W 2 [0
0x39FF Reset Delay F003 1.000 R/W 2 [0
0x3A01 Minimum Voltage F003 1.000 R/W 2 [10
0x3A03 Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x3A04 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x3A16 Confirmation address W 1
Ajustes unidad Sobrefrequencia 5- Overfrequency 5 Settings
0x4A29 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A2A Pickup Level F003 1.000 R/W 2 [20
0x4A2C Trip Delay F003 1.000 R/W 2 [0
0x4A2E Reset Delay F003 1.000 R/W 2 [0
0x4A30 Minimum Voltage F003 1.000 R/W 2 [10
0x4A32 Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A33 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x4A37 Confirmation address W 1
