APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-151
Ajustes de unidad de Subfrecuencia 5- Underfrequency 5 Settings
0x4A38 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A39 Pickup Level F003 1.000 R/W 2 [20
0x4A3B Trip Delay F003 1.000 R/W 2 [0
0x4A3D Reset Delay F003 1.000 R/W 2 [0
0x4A3F Minimum Voltage F003 1.000 R/W 2 [10
0x4A41 Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A42 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x4A46 Confirmation address W 1
Ajustes de unidad de sobrefrequencia 6- Overfrequency 6 Settings
0x4A47 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A48 Pickup Level F003 1.000 R/W 2 [20
0x4A4A Trip Delay F003 1.000 R/W 2 [0
0x4A4C Reset Delay F003 1.000 R/W 2 [0
0x4A4E Minimum Voltage F003 1.000 R/W 2 [10
0x4A50 Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A51 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x4A55 Confirmation address W 1
Ajustes de unidad de subfrequencia 6- Underfrequency 6 Settings
0x4A56 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A57 Pickup Level F003 1.000 R/W 2 [20
0x4A59 Trip Delay F003 1.000 R/W 2 [0
0x4A5B Reset Delay F003 1.000 R/W 2 [0
0x4A5D Minimum Voltage F003 1.000 R/W 2 [10
0x4A5F Snapshot Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A60 Frequency Source F012 1.000 R/W 1 0=LINE FRQ
1=BUS FRQ
0x4A64 Confirmation address W 1
Ajustes de unidad de 60CTs- 60CTS Failure Settings
0x4A65 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A66 3IO Current PKP F003 1.000 R/W 2 [0
0x4A68 3VO Voltage Inhibit F003 1.000 R/W 2 [0
0x4A6A GND Current Inhibit F003 1.000 R/W 2 [0
0x4A6C SGND Current Inhibit F003 1.000 R/W 2 [0
0x4A6E Time Delay F003 1.000 R/W 2 [0
0x4A70 Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A78 Confirmation address W 1
Ajustes de unidad de bloqueo por 2nd armónico-2nd HRMC Inhibit Settings
0x4A79 Function F012 1.000 R/W 1 0=DISABLED
1=ENABLED
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
