B-152 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
0x4A7A Pickup F003 1.000 R/W 2 [1
0x4A7C Delay F003 1.000 R/W 2 [0
0x4A7E Minimum Current F003 1.000 R/W 2 [0
0x4A80 Phases For Operation F012 1.000 R/W 1 0=ANY ONE
1=ANY TWO
2=ALL THREE
3=AVERAGE
0x4A81 Events F012 1.000 R/W 1 0=DISABLED
1=ENABLED
0x4A87 Confirmation address W 1
Datos Ecuaciones PLC - PLC Data
0x6000 PLC equations F009 R 15360
Datos Display Gráfico - LCD Data
0x9C00 LCD configuration R 768
Bits de Maniobra (24 bits) - Commands
0xAFFE 0x0001 Operation 1 F001 W 1
0xAFFE 0x0002 Operation 2 F001 W 1
0xAFFE 0x0004 Operation 3 F001 W 1
0xAFFE 0x0008 Operation 4 F001 W 1
0xAFFE 0x0010 Operation 5 F001 W 1
0xAFFE 0x0020 Operation 6 F001 W 1
0xAFFE 0x0040 Operation 7 F001 W 1
0xAFFE 0x0080 Operation 8 F001 W 1
0xAFFE 0x0100 Operation 9 F001 W 1
0xAFFE 0x0200 Operation 10 F001 W 1
0xAFFE 0x0400 Operation 11 F001 W 1
0xAFFE 0x0800 Operation 12 F001 W 1
0xAFFE 0x1000 Operation 13 F001 W 1
0xAFFE 0x2000 Operation 14 F001 W 1
0xAFFE 0x4000 Operation 15 F001 W 1
0xAFFE 0x8000 Operation 16 F001 W 1
0xAFFF 0x0001 Operation 17 F001
W 1
0xAFFF 0x0002 Operation 18 F001 W 1
0xAFFF 0x0004 Operation 19 F001 W 1
0xAFFF 0x0008 Operation 20 F001 W 1
0xAFFF 0x0010 Operation 21 F001 W 1
0xAFFF 0x0020 Operation 22 F001 W 1
0xAFFF 0x0040 Operation 23 F001 W 1
0xAFFF 0x0080 Operation 24 F001 W 1
Identificación del Equipo - Relay Identification
0xB000 Relay model F009 R 8
0xB008 Firmware version F009 R 2
0xB018 Year(0=2000,1=2001,...) and part
of f
irmware compilation
F001 R 1
0xB019 Day and month of firmware
compilation
F001 R 1
0xB020 Address of PLC equations F005 R 2
0xB022 Address of LCD configuration F005 R 2
0xB027 MAC Address F009 R 6
0xB02D Serial Number F009 R 4
0xB031 Manufacturing Date F009 R 8
