APPENDIX B: MODBUS PROTOCOL B.5 MEMORY MAP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER B-153
Eventos de Control y Panel de Alarmas - Control Events & Alarm Panel
0xF000 Status and acknowledge of the
192 c
ontrol events
F001 R 24 Status = 24 first bytes
1st byte: 1st eight control events (First
ev
ent=bit less significant)
2nd byte: 2nd eight control events (Ninth
ev
ent=bit less significant)
. . .
Ack = 24 second bytes
25th byte: 1st eight control events (First
ev
ent=bit less significant)
26th byte: 2nd eight control events
(Ni
nth event=bit less significant)
. . .
0xF018 Indicate which control events are
c
onfigurated as alarm
F001 R 12 1st byte: 1st eight control events (First
event=bit less significant)
2nd byte: 2nd eight control events (Ninth
ev
ent=bit less significant)
. . .
0xF024 Date/Time of the 1-16 alarms F011 R 64
0xF064 Date/Time of the 17-32 alarms F011 R 64
0xF0A4 Date/Time of the 33-48 alarms F011 R 64
0xF0E4 Date/Time of the 49-64 alarms F011 R 64
0xF124 Date/Time of the 65-80 alarms F011 R 64
0xF164 Date/Time of the 81-96 alarms F011 R 64
0xF1A4 Date/Time of the 97-112 alarms F011 R 64
0xF1E4 Date/Time of the 113-128
alar
ms
F011 R 64
0xF224 Date/Time of the 129-144
alar
ms
F011 R 64
0xF264 Date/Time of the 145-160
alar
ms
F011 R 64
0xF2A4 Date/Time of the 161-176
alar
ms
F011 R 64
0xF2E4 Date/Time of the 177-192
alar
ms
F011 R 64
0xF324 Alarm acknowledge
F001 W 12 1st byte: 1st eight alarms (First alarm=bit
less significant)
2nd byte: 2nd eight alarms (Ninth
alarm=
bit less significant)
. . .
Entradas Virtuales - Virtual Inputs
0xF430 64 Virtual Inputs (32 Latched +
32 Self R
eset)
F001 R/W 4 2nd byte: 1st eight virtual inputs (First
virtual input=bit less significant)
1st byte: 2nd eight virtual inputs (Ninth
vi
rtual input=bit less significant)
. . .
Nombre Fichero de Eventos - Events File Name
0xFE00 Name of the events file to read F009 W EVE.TXT: all snapshot-events are sent in
ASCII form
at
NEW_EVE.TXT: the new snapshot-events
ar
e sent in ASCII format
EVE.BIN: all snapshot-events are sent in
BINARY format
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
