B-154 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
B.5 MEMORY MAP APPENDIX B: MODBUS PROTOCOL
NEW_EVE.BIN: the new snapshot-events
are sent in BINARY format
Forzado de Salidas por Comunicaciones - Forcing Outputs
0xFE20 Opening force output file F004 W 3 Write "OUTPUT"
0xFE28 Closing force output file F004 W 3 Write "OUTPUT"
0xFF20 Forcing outputs F004 W 5
First word = Board number;
Ficheros Oscilografía y Reporte de Faltas - Oscillography and Fault Report Files
0xFE40 Name of the oscillography/fault
re
port file to read
F009 W OSCXXX.DAT, OSCXXX.CFG, OSCXXX.HDR
FLTXXX.TXT (where XXX=001 to 999)
Sucesos - Snapshot events
0xFF00 Character position of current
bloc
k within events file
F005 R 2
0xFF02 Size of currently-available data
block of events file
F004 R 1
0xFF03 Block of data requested events
f
ile (122 items)
F004 R 1
Ficheros Oscilografía y Reporte de Faltas - Oscillography and Fault Report Files
0xFF40 Character position of current
bloc
k within osc file
F005 R 2
0xFF42 Size of currently-available data
bloc
k of osc file
F004 R 1
0xFF43 Block of data requested osc file
(122
items)
F004 R 1
Sincronización Horaria - Synchronization
0xFFF0 Synchronization (miliseconds
fr
om 01/01/2000)
F011 R/W 4
DESCRIPCIÓN FORMATO DE DATOS - FORMATS DESCRIPTION
F001 UNSIGNED INT 16 BIT (BITMASK)
F002 SIGNED INT 32 BIT
F003 FLOAT 32 BIT
F004 SIGNED INT 16 BIT
F005 SIGNED INT 32 BIT
F006 DOUBLE 64 BIT
F007 UNSIGNED INT 8 BIT
F008 SIGNED INT 8 BIT
F009 STRING
F011 UNSIGNED INT 64 BIT
(M
ILISECONDS FROM 01/01/
2000)
F012 UNSIGNED INT 16 BIT
(E
NUMERATED)
ADDRESS BIT NAME FORMAT STEP MODE LENGTH MISCELLANEOUS
