c-2 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
C.1 DNP 3.0 PROTOCOL SETTINGS APPENDIX C: DNP 3.0 PROTOCOL FOR F650
17 IP Addr Client4 Oct3 0 0 to 255 step 1
18 IP Addr Client4 Oct4 0 0 to 255 step 1
19 IP Addr Client5 Oct1 0 0 to 255 step 1
20 IP Addr Client5 Oct2 0 0 to 255 step 1
21 IP Addr Client5 Oct3 0 0 to 255 step 1
22 IP Addr Client5 Oct4 0 0 to 255 step 1
23 TCP/UDP Port 20000 1 to 65535, step 1
24 Unsol Resp Function DISABLED DISABLED, ENABLED
25 Unsol Resp TimeOut 5 s 0 to 60 sec, step 1
26 Unsol Resp Max Ret 10 1 to 255, step 1
27 Unsol Resp Dest Adr 200 0 to 65519, step 1
28 Current Scale Factor 1 0.00001, 0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000
29 Voltage Scale Factor 1 0.00001, 0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000
30 Power Scale Factor 1 0.00001, 0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000
31 Energy Scale Factor 1 0.00001, 0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000
32 Other Scale Factor 1 0.00001, 0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000
33 Current Deadband 30000 0 to 65535, step 1
34 Voltage Deadband 30000 0 to 65535, step 1
35 Power Deadband 30000 0 to 65535, step 1
36 Energy Deadband 30000 0 to 65535, step 1
37 Other Deadband 30000 0 to 65535, step 1
38 Msg Fragment Size 240 30 to 2048, step 1
39 Binary Input Block1 CTL EVENTS 1-16
See the explanation below
Setting No Setting Name Default Value Range
40 Binary Input Block2 CTL EVENTS 17-32 See the explanation below
41 Binary Input Block3 CTL EVENTS 33-48 See the explanation below
42 Binary Input Block4 CTL EVENTS 49-64 See the explanation below
43 Binary Input Block5 CTL EVENTS 65-80 See the explanation below
44 Binary Input Block6 CTL EVENTS 81-96 See the explanation below
45 Binary Input Block7 CTL EVENTS 97-112 See the explanation below
46 Binary Input Block8 CTL EVENTS 113-128 See the explanation below
47 Binary Input Block9 SWITCHGEAR 1-8 See the explanation below
48 Binary Input Block10 SWITCHGEAR 9-16 See the explanation below
49 Default analog Map Disabled See the explanation below
50 Analog Input Point 0 End Of List See the explanation below
51 Analog Input Point 1 End Of List See the explanation below
52 Analog Input Point 2 End Of List See the explanation below
53 Analog Input Point 3 End Of List See the explanation below
54 Analog Input Point 4 End Of List See the explanation below
55 Analog Input Point 5 End Of List See the explanation below
56 Analog Input Point 6 End Of List See the explanation below
57 Analog Input Point 7 End Of List See the explanation below
58 Analog Input Point 8 End Of List See the explanation below
59 Analog Input Point 9 End Of List See the explanation below
60 Analog Input Point 10 End Of List See the explanation below
61 Analog Input Point 11 End Of List See the explanation below
62 Analog Input Point 12 End Of List See the explanation below
63 Analog Input Point 13 End Of List See the explanation below
64 Analog Input Point 14 End Of List See the explanation below
65 Analog Input Point 15 End Of List See the explanation below
66 Analog Input Point 16 End Of List See the explanation below
