APPENDIX C: DNP 3.0 PROTOCOL FOR F650 C.1 DNP 3.0 PROTOCOL SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER c-3
1. Physical Port: The F650 supports the Distributed Network Protocol (DNP) version 3.0. The F650 can be used as a
DNP slave device connected up to three DNP masters (usually RTUs or SCADA master stations). The Physical Port
setting is used to select the communications port assigned to the DNP protocol for a specific logical DNP slave
device of F650. When this setting is set to NETWORK, the DNP protocol can be used over either TCP/IP or UDP/IP.
2. Address: This setting is the DNP slave address. This number identifies de F650 on a DNP communications link. Each
logical DNP slave should be assigned a unique address.
3-22. IP Addr Client x Oct x: this setting is one of four octets of an IP address. The F650 relay can respond to a maximum
of 5 specific DNP masters (not in the same time). To set the IP address of DNP master it is necessary to set four
octets (e.g. to set the IP address of the first DNP master to 192.168.48.125, you should set IP Addr Client1 Oct1 =
192, IP Addr Client1 Oct2 = 168, IP Addr Client1 Oct3 = 48, IP Addr Client1 Oct4 = 125).
23. TCP/UDP Port: TCP/UDP port number for the case of DNP3 communication being performed through the Ethernet.
24. Unsol Resp Function: ENABLED, if unsolicited responses are allowed, and DISABLED otherwise.
25. Unsol Resp TimeOut: sets the time the F650 waits for a DNP master to confirm an unsolicited response.
26. Unsol Resp Max Ret: This setting determines the number of times the F650 retransmits an unsolicited response
without receiving a confirmation from the master. Once this limit has been exceeded, the unsolicited response is
sent at a larger interval. This interval is called the unsolicited offline interval and is fixed at 10 minutes.
27. Unsol Resp Dest Adr: This setting is DNP address to which all unsolicited responses are sent. The IP address to
which unsolicited responses are sent is determined by the F650 from either the current DNP TCP connection or the
most recent UDP message.
28-32. Scale Factor: These settings are numbers used to scale Analog Input point values. These settings group the F650
Analog Input data into types: current, voltage, power, energy, and other. Each setting represents the scale factor
for all Analog Input points of that type. For example, if the Voltage Scale Factor is set to a value of 1000, all DNP
Analog Input points that are voltages are returned with the values 1000 times smaller (e.g. a value 72000 V on the
F650 is returned as 72). These settings are useful when Analog Input values must be adjusted to fit within certain
ranges in DNP masters. Note that a scale factor of 0.1 is equivalent to a multiplier of 10 (i.e. the value is 10 times
larger).
33-37. Deadband: These settings are the values used by the F650 to determine when to trigger unsolicited responses
containing Analog Input data. These settings group the F650 Analog Input data into types: current, voltage, power,
energy, and other. Each setting represents the default deadband value for all Analog Input points of that type. For
example, in order to trigger unsolicited responses from the F650 when any current values change by 15 A, the
Current Deadband setting should be set to 15. Note that these settings are the default values of the deadbands.
DNP object 34 points can be used to change deadband values, from the default, for each individual DNP Analog
Input point. Whenever power is removed and re-applied to the F650, the default deadbands are in effect.
67 Analog Input Point 17 End Of List See the explanation below
68 Analog Input Point 18 End Of List See the explanation below
69 Analog Input Point 19 End Of List See the explanation below
70 Analog Input Point 20 End Of List See the explanation below
71 Analog Input Point 21 End Of List See the explanation below
72 Analog Input Point 22 End Of List See the explanation below
73 Analog Input Point 23 End Of List See the explanation below
74 Analog Input Point 24 End Of List See the explanation below
75 Analog Input Point 25 End Of List See the explanation below
76 Analog Input Point 26 End Of List See the explanation below
77 Analog Input Point 27 End Of List See the explanation below
78 Analog Input Point 28 End Of List See the explanation below
79 Analog Input Point 29 End Of List See the explanation below
80 Analog Input Point 30 End Of List See the explanation below
81 Analog Input Point 31 End Of List See the explanation below
