APPENDIX C: DNP 3.0 PROTOCOL FOR F650 C.8 ANALOG INPUTS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER c-21
12 I1 Primary kA / A
13 I2 Primary kA / A
14 V0 Primary kV / V
15 V1 Primary kV / V
16 V2 Primary kV / V
17 Vab Primary kV / V
18 Vbc Primary kV / V
19 Vca Primary kV / V
20 Vn Primary kV / V
21 Va Primary kV / V
22 Vb Primary kV / V
23 Vc Primary kV / V
24 VL Primary kV / V
25 VBB Primary kV / V
26 Phase A Reactive Pwr MVAr / kVAr
27 Phase A Apparent Pwr MVA / kVA
28 Phase A Real Pwr MW / kW
29 Phase B Reactive Pwr MVAr / kVAr
30 Phase B Apparent Pwr MVA / kVA
31 Phase B Real Pwr MW / kW
32 Phase C Reactive Pwr MVAr / kVAr
33 Phase C Apparent Pwr MVA / kVA
34 Phase C Real Pwr MW / kW
35 3 Phase Reactive Pwr MVAr / kVAr
36 3 Phase Apparent Pwr MVA / kVA
37 3 Phase Real Pwr MW / kW
38 Phase A Power Factor
39 Phase B Power Factor
40 Phase C Power Factor
41 3 Phase Power Factor
42 Line Frequency Primary Hz
43 Bus Frequency Primary Hz
44 Vx Primary kV / V
45 Pos MVarhour Freeze MVArh / kVArh
46 Neg MVarhour Freeze MVArh / kVArh
47 Pos MWatthour Freeze MWh / kWh
48 Pos MWatthour Freeze MWh / kWh
49 Positive MVarhour MVArh / kVArh
50 Negative MVarhour MVArh / kVArh
51 Positive MWatthour MWh / kWh
52 Negative MWatthour MWh / kWh
53 Fault 1 Prefault Phase A Current Magnitude kA / A
54 Fault 1 Prefault Phase A Current Angle degrees
55 Fault 1 Prefault Phase B Current Magnitude kA / A
56
Fault 1 Prefault Phase B Current Angle degrees
57 Fault 1 Prefault Phase C Current Magnitude kA / A
58 Fault 1 Prefault Phase C Current Angle degrees
59 Fault 1 Prefault Phase AB Voltage Magnitude kV / V
60 Fault 1 Prefault Phase AB Voltage Angle degrees
61 Fault 1 Prefault Phase BC Voltage Magnitude
kV / V
POINT DESCRIPTION UNIT
