c-22 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
C.8 ANALOG INPUTS APPENDIX C: DNP 3.0 PROTOCOL FOR F650
62 Fault 1 Prefault Phase BC Voltage Angle degrees
63 Fault 1 Prefault Phase CA Voltage Magnitude kV / V
64 Fault 1 Prefault Phase CA Voltage Angle degrees
65 Fault 1 Postfault Phase A Current Magnitude kA / A
66 Fault 1 Postfault Phase A Current Angle degrees
67 Fault 1 Postfault Phase B Current Magnitude kA / A
68 Fault 1 Postfault Phase B Current Angle degrees
69 Fault 1 Postfault Phase C Current Magnitude kA / A
70 Fault 1 Postfault Phase C Current Angle degrees
71 Fault 1 Postfault Phase AB Voltage Magnitude kV / V
72 Fault 1 Postfault Phase AB Voltage Angle degrees
73 Fault 1 Postfault Phase BC Voltage Magnitude kV / V
74 Fault 1 Postfault Phase BC Voltage Angle degrees
75 Fault 1 Postfault Phase CA Voltage Magnitude kV / V
76 Fault 1 Postfault Phase CA Voltage Angle degrees
77 Fault 1 Type Enum
78 Fault 1 Location km
79 Fault 1 Prefault Ground Current Magnitude kA / A
80 Fault 1 Prefault Ground Current Angle degrees
81 Fault 1 Prefault Sensitive Ground Current Magnitude kA / A
82 Fault 1 Prefault Sensitive Ground Current Angle degrees
83 Fault 1 Postfault Ground Current Magnitude kA / A
84 Fault 1 Postfault Ground Current Angle degrees
85 Fault 1 Postfault Sensitive Ground Current Magnitude kA / A
86 Fault 1 Postfault Sensitive Ground Current Angle degrees
87 % of Load to Trip %
88 Board F - Analog 1
89 Board F - Analog 2
90 Board F - Analog 3
91 Board F - Analog 4
92 Board F - Analog 5
93 Board F - Analog 6
94 Board F - Analog 7
95 Board F - Analog 8
96 Board G - Analog 1
97 Board G - Analog 2
98 Board G - Analog 3
99 Board G - Analog 4
100 Board G - Analog 5
101 Board G - Analog 6
102 Board G - Analog 7
103 Board G - Analog 8
104 Board H - Analog 1
105 Board H - Analog 2
106 Board H - Analog 3
107 Board H - Analog 4
108 Board H - Analog 5
109 Board H - Analog 6
110 Board H - Analog 7
111 Board H - Analog 8
POINT DESCRIPTION UNIT
