GE Multilin F650 - Page 956

D-6 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
D.4 IEC 104 SETTINGS APPENDIX D: IEC 60870-5-104 PROTOCOL
Group 3 Status
POINT DESCRIPTION
M_DP_NA_1
1500-1515 SWITCHGEAR EVENTS
Group 4 Status
POINT DESCRIPTION
M_SP_NA_1
1128-1255 BOARD F 1-32, G 1-32, H 1-32, J 1-32
Group 5 Single point
POINT DESCRIPTION
M_ME_NC_1
2000 Phasor Ia Primary
2001 Phasor Ib Primary
2002 Phasor Ic Primary
2003 Phasor Ig Primary
2004 Phasor Isg Primary
2005 Phasor In Primary
2006 RMS Ia Primary
2007 RMS Ib Primary
2008 RMS Ic Primary
2009 RMS Ig Primary
2010 RMS Isg Primary
2011 I0 Primary
2012 I1 Primary
2013 I2 Primary
2014 V0 Primary
2015 V1 Primary
2016 V2 Primary
2017 Vab Primary
2018 Vbc Primary
2019 Vca Primary
2020 Vn Primary
2021 Va Primary
2022 Vb Primary
2023 Vc Primary
2024 VL Primary
2025 VBB Primary
2026 Phase A Reactive Pwr
2027 Phase A Apparent Pwr
