APPENDIX D: IEC 60870-5-104 PROTOCOL D.4 IEC 104 SETTINGS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER d-7
2028 Phase A Real Pwr
2029 Phase B Reactive Pwr
2030 Phase B Apparent Pwr
2031 Phase B Real Pwr
2032 Phase C Reactive Pwr
2033 Phase C Apparent Pwr
2034 Phase C Real Pwr
2035 3 Phase Reactive Pwr
2036 3 Phase Apparent Pwr
2037 3 Phase Real Pwr
2038 Phase A Power Factor
2039 Phase B Power Factor
2040 Phase C Power Factor
2041 3 Phase Power Factor
2042 Line Frequency Primary
2043 Bus Frequency Primary
2044 Vx Primary
2045 Pos Mvarhour Freeze
2046 Neg Mvarhour Freeze
2047 Pos MWatthour Freeze
2048 Neg MWatthour Freeze
2049 Positive MVarhour
2050 Negative MVarhour
2051 Positive MWatthour
2052 Negative MWatthour
2053 Fault 1 Prefault Phase A Current Magnitude
2054 Fault 1 Prefault Phase A Current Angle
2055 Fault 1 Prefault Phase B Current Magnitude
2056 Fault 1 Prefault Phase B Current Angle
2057 Fault 1 Prefault Phase C Current Magnitude
2058 Fault 1 Prefault Phase C Current Angle
2059 Fault 1 Prefault Phase AB Voltage Magnitude
Group 6 Metering
POINT DESCRIPTION
M_ME_NC_1
2060 Fault 1 Prefault Phase AB Voltage Angle
2061 Fault 1 Prefault Phase BC Voltage Magnitude
2062 Fault 1 Prefault Phase BC Voltage Angle
2063 Fault 1 Prefault Phase CA Voltage Magnitude
Group 5 Single point
To Next Page
