D-8 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
D.4 IEC 104 SETTINGS APPENDIX D: IEC 60870-5-104 PROTOCOL
2064 Fault 1 Prefault Phase CA Voltage Angle
2065 Fault 1 Postfault Phase A Current Magnitude
2066 Fault 1 Postfault Phase A Current Angle
2067 Fault 1 Postfault Phase B Current Magnitude
2068 Fault 1 Postfault Phase B Current Angle
2069 Fault 1 Postfault Phase C Current Magnitude
2070 Fault 1 Postfault Phase C Current Angle
2071 Fault 1 Postfault Phase AB Voltage Magnitude
2072 Fault 1 Postfault Phase AB Voltage Angle
2073 Fault 1 Postfault Phase BC Voltage Magnitude
2074 Fault 1 Postfault Phase BC Voltage Angle
2075 Fault 1 Postfault Phase CA Voltage Magnitude
2076 Fault 1 Postfault Phase CA Voltage Angle
2077 Fault 1 Type
2078 Fault 1 Location
2079 Fault 1 Prefault Ground Current Magnitude
2080 Fault 1 Prefault Ground Current Angle
2081 Fault 1 Prefault Sensitive Ground Current Magnitude
2082 Fault 1 Prefault Sensitive Ground Current Angle
2083 Fault 1 Postfault Ground Current Magnitude
2084 Fault 1 Postfault Ground Current Angle
2085 Fault 1 Postfault Sensitive Ground Current Magnitude
2086 Fault 1 Postfault Sensitive Ground Current Angle
2087 % of Load to Trip
2088 Board F – Analog 1
2089 Board F – Analog 2
2090 Board F – Analog 3
2091 Board F – Analog 4
2092 Board F – Analog 5
2093 Board F – Analog 6
2094 Board F – Analog 7
2095 Board F – Analog 8
2096 Board G – Analog 1
2097 Board G – Analog 2
2098 Board G – Analog 3
2099 Board G – Analog 4
2100 Board G – Analog 5
2101 Board G – Analog 6
2102 Board G – Analog 7
2103 Board G – Analog 8
2104 Board H – Analog 1
Group 6 Metering
To Next Page
