F-4 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
F.1 IEC 60870-5-103 PROTOCOL APPENDIX F: IEC 60870-5-103 PROTOCOL
Auto-reclosure indications in monitor direction
Measurands in monitor direction
<77> Teleprotection signal
received
<78> Zone 1
<79> Zone 2
<80> Zone 3
<81> Zone 4
<82> Zone 5
<83> Zone 6
X
<84> General start / pick-up 4003|4019|4035|4051|4067|4083|41
70|4188|4206|565
7|5675|5693|4112
|4120|4128|4239|4248|4257
PH H/L / GND IOC/
T
OC 1/2/3 PKP
X <85> Breaker failure 4537 BKR FAIL INITIATE
<86> Trip measuring system L1
<87> Trip measuring system L2
<88> Trip measuring system L3
<89> Trip measuring system E
X <90> Trip I> 4004|4020|4036|4052|4068|4084 PH IOC 1/2/3 H/L OP
X
<91> Trip I>> 4171|4189|4207|5658|5676|5694 PH TOC 1/2/3 H/L
OP
X <92> Trip IN> 4113|4121|4129 GND IOC 1/2/3 OP
X <93> Trip IN>> 4240|4249|4258 GND TOC 1/2/3 OP
INF Semantics F650 Identifier F650 Data Text
X <128> CB 'on' by AR 4586 AR CLOSE BREAKER
<129> CB 'on' by long-time AR
X <130> AR blocked 4593 AR BLOCK
INF Semantics F650 Identifier F650 Data Text
X <144> Measurand I 5064 Ib Primary
X <145> Measurands I, V 5064-5080 Ib,Vab Primary
X
<146> Measurands I, V, P, Q 5064-5080-5099-
5100
Ib,Vab,P,Q Primary
X
<147> Measurands In, Vn 5066-5086 Ig Primary, Vn
Primary
X
<148> Measurands IL123, VL123, P, Q, f 5063-5064-5065-
5083-5084-50
85-
5099-5100-3969
Ia,Ib,Ic,Va,Vb,Vc,P,Q
Prim
ary ,Line
Frequency
