IBM Storwize V7000 Unified Problem Determination Guide

Table 16. Storwize V7000 2076-524 node canister system status LEDs (continued)
Name Call out Color State Meaning
Canister fault ▌9▐ Amber OFF The canister is
able to function
as an active
member of the
system. If there
is a problem on
the node
canister, it is not
severe enough to
stop the node
canister from
completing I/O
operations.
BLINK The canister is
being identified.
There might or
might not be a
fault condition.
ON The node is in
service state or
an error exists
that might be
stopping the
system code
from starting.
The node
canister cannot
become active in
the system until
the problem is
resolved. You
must determine
the cause of the
error before
replacing the
node canister.
The error may
be due to
insufficient
battery charge;
in this event,
resolving the
error simply
requires waiting
for the battery to
charge.
USB ports in the Storwize V7000 Gen2 node canister
Two USB ports are located on each Storwize V7000 Gen2 node canister.
The USB ports are numbered 1 on top and 2 on the bottom as shown in Figure 23
on page 21. One port is used during installation.
20 Storwize V7000 Unified: Problem Determination Guide 2073-720

IBM Storwize V7000 Unified Specifications

General

Model	IBM Storwize V7000 Unified
Storage Type	Unified Storage
RAID Levels	RAID 0, 1, 5, 6, 10
Form Factor	2U
Drive Types Supported	SAS, SSD
Maximum Drives	504
Network Protocols	iSCSI, FC, FCoE
Drive Bays	24 per enclosure
Host Interface	8 Gb FC, 1 Gb/10 Gb iSCSI
File Protocols	NFS, CIFS
Block Protocols	iSCSI, Fibre Channel
Type	Unified Storage
Maximum Host Ports	16
Operating System Support	VMware, Microsoft Windows, Linux, AIX
Data Services	Thin provisioning, replication
Power Supply	Redundant power supplies
Host Interfaces	8 Gbps Fibre Channel, 10 Gbps iSCSI, 1 Gbps iSCSI
