Keithley 4200-SCS User Manual

3-62 Return to Section Topics 4200-900-01 Rev. K / February 2017
Section 3: Common Device Characterization Tests Model 4200-SCS User’s Manual
Table 3-17
Outputs for Vgid_DC_Pulse_pulseiv
Output Type Description
DrainI_DC/Pulse double The measured drain current from channel 2 of the 4200-SCP2 or the
DrainSMU. In the case of Pulse, this current is determined by
measuring the voltage drop across the 4200-SCP2 50 Ω
termination, giving Id = Vd / 50
Ω.
DrainVMeas_DC/Pulse double The measured drain voltage from channel 2 of the 4200-SCP2 in the
case of pulse and the measured voltage on the DrainSMU in the
case of DC.
DrainV_Prog_DC/
Pulse
double The programmed drain voltage, either supplied by the pulse card or
the SMU for the drain.
GateVMeas_DC/Pulse double The measure gate voltage from channel 1 of the 4200-SCP2 in the
case of pulse and the measured voltage on the GateSMU in the
case of DC.
GateVProg_DC/Pulse double The programmed gate voltage, either supplied by the pulse card or
Gate SMU.
Table 3-18
Return values for Vgid_DC_Pulse_pulseiv
Value Description
0
OK
-1 Invalid value for Vds
-2 Invalid value for VgStart
-3 Invalid value for VgStop
-4 Invalid value for VgStep
-5 Invalid value for PulseWidth
-6 Invalid value for PulsePeriod
-7 Invalid value for AverageNum
-8 Invalid value for LoadLineCorr
-9 Array sizes do not match
-10 Array sizes not large enough for sweep
-11 Invalid VPUId
-12 Invalid GateSMU
-13 Invalid DrainSMU
-14 Unable to initialize PIV solution
-15 Invalid GateSMU Range
-16 Invalid DrainSMU Range
