Direct connection to single DUT
Cabling instructions for direct connect to single DUT are below. Refer to Figure
3-95 for the following procedure.
NOTE In all of the following steps apply sufficient torque using the wrench.
These instructions are compatible with the following projects in the
Projects\_Memory folder:
•Flash-NAND
•Flash-NOR
• FlashDisturb-NAND
• FlashDisturb-NOR
• FlashEndurance-NAND
• FlashEndurance-NOR
1. Set up the 4200-SCS, referring to the Getting Started, page 1-1, Reference manual,
Installation, page 2-1, and Reference manual, Connections and Configuration, page 4-1.
For examples of cables, adapters, and connectors see Reference manual, Figure 11-35.
2. Take one of the SMA Tees and connect the two shortest (4.25 inch or 10.8 cm) SMA cables
to either end.
3. Connect this assembly to the right-most PG2 card, that is, the PG2 card in the lowest
numbered slot.
• First connect one of the SMA cables to TRIGGER OUT.
• Connect the SMA tee to TRIGGER IN.
4. Then connect the other SMA cable to TRIGGER IN on the second PG2 card. This second
card is the card to the immediate left of the card in step 3.
NOTE If the FLASH package consists of more than two PG2 cards, continue to connect the
cable and Tees to the adjacent cards. Torque both connections using the wrench.
For a system consisting of four PG2 cards, there should be three SMA tees used to
connect the triggering across the four cards.
5. Take an SMA Tee and connect one SMA-to-BNC adapter to one of the female connectors.
6. Connect the assembly from step 5 to one Triax-to-SMA Adapter.
7. Connect one 8 inch (20.3 cm) SMA cable to the remaining SMA female connector.
8. Connect one 5 foot (1.5 m) black BNC cable to the BNC connection.
9. Perform steps 5-8 three more times.
10. Take one of the cable assemblies from step 9, connect the SMA to CHANNEL 2 of the PG2
in the left most slot (PG2 in the slot with the highest number).
11. Carefully insert the LEMO Triax connector from step 10 into the Force connector on the
SMU in Slot 4.
12. Route BNC cable from SMU4 to the DUT terminal Bulk connection. Connect Triax-to-BNC
adapter, if necessary. Connect cable to probe manipulator.
13. Take one of the cable assemblies from step 9, connect the SMA to CHANNEL 1 of the PG2
in the left most slot (PG2 in the slot with the highest number).
14. Carefully insert the LEMO Triax connector from step 13 into the Force connector on the
SMU in Slot 3.
