Keithley 4200-SCS User Manual

4200-900-01 Rev. K / February 2017 Return to Section Topics 3-31
Model 4200-SCS User’s Manual Section 3: Common Device Characterization Tests
Supplied tools
The following tools are supplied with the 4200-SCS or PIV-A package:
• #1 Phillips screwdriver
• Torque wrench, 8 in./lb, with 5/16 in. head installed
NOTE The various adapters, cables and hardware used for the pulse projects are shown in
the Reference manual, Figure 11-35.
Figure 3-26
Pulse IV — hardware connections
Table 3-2
Supplied interconnect parts for 4200-PIV-A
Qty Description Comment
1 4.25 in / 10.8 cm white SMA cable Interconnect for trigger
2 6 in / 15 cm white SMA cables Interconnect between RBT and prober manipulator
2 13 in / 33 cm white SMA cables Interconnect between RBT and prober manipulator (optional)
3 6.6 ft / 2 m white SMA cables Interconnect between SCP2, pulse generator and RBTs
4 6.6 ft / 2 m black Triax cables Interconnect between SMUs and RBTs
2 SMA female to BNC Male Adapt SCP2 BNC channels to SMA
1 SMA female to SMB plug Adapt SCP2 SMB trigger to SMA
1 Power Divider, Male/Female/Male Connects to Gate side RBT AC IN connector
Model 4200-SCS
Instrument Slots
4205
PG2
4200
SCP2
V
D
V
G
INSTRUMENTS
SLOT
8
SLOT
7
SLOT
6
SLOT
5
SLOT
4
SLOT
3
SLOT
2
SLOT
1
4200
SMU
SENSE LO
SENSE
FORCE
PA CNTRL
KEITHLEY
4200
SMU
SENSE LO
SENSE
FORCE
PA CNTRL
KEITHLEY
4210
SMU
SENSE LO
SENSE
FORCE
PA CNTRL
KEITHLEY
4210
SMU
SENSE LO
SENSE
FORCE
PA CNTRL
KEITHLEY
KEITHLEY
Channel 1
Channel 2
Ext
Trg
Ext
Clk
NOTE Use torque wrench to tighten SMA
connections to 8 inch-lbs.
Scope Card
Model 4205-PG2
Model 4200-SMU (1)
Model 4200-SMU (2)
AC+DC
Output
AC+DC Output
Substrate
Source
Gate
Drain
Model 4205-RBT (2)
SENSE
AC+DC
OUTPUT
FORCE
AC
INPUT
CHANNEL 1
KEITHLEY
TRIGGER
OUT
CHANNEL 2
TRIGGER
IN
3-port
power
divider
1
2
S
Model 4205-RBT (1)
SENSE
AC+DC
OUTPUT
FORCE
AC
INPUT
= SMB Male to SMA Female Adapter
= BNC Male to SMA Female Adapter
White SMA Cable
(15cm, 6in)
(male-to-male)
White SMA Cable (2m, 6ft)
(male-to-male)
1 of 5
4200-MTRX-X
Cable (2m, 6ft)
(1 of 4)
