2-32 Return to Section Topics 4200-900-01 Rev. K / February 2017
Section 2: Model 4200-SCS Software Environment Model 4200-SCS User’s Manual
How to manage numeric test results in Sheet tab
Displaying and analyzing data using Sheet tab
The Sheet tab of an ITM or UTM window is used to record and manipulate numerical test data and
settings. There is a Sheet tab corresponding to every ITM / UTM for each site. All data in the
worksheets of the Sheet tab is exportable in Microsoft
®
Excel
®
format.
A Sheet tab is the same as a Microsoft
®
Excel
®
workbook that always contains at least the
following three worksheets:
• Data worksheet: The Data worksheet of the Sheet tab records all of the numerical test data
that is generated every time you execute an ITM or a UTM at a given site. The Sheet tab
Data worksheet also records data generated by the formulator.
• Calc worksheet: The Sheet tab Calc worksheet provides a spreadsheet for local data
analysis. If there are multiple same-named instances of an ITM or UTM in a project plan, the
Calc worksheet equations are unique for each instance.
• Settings worksheet: The Sheet tab settings worksheet documents the test configuration
and site number.
A Sheet tab may also contain one or more Append worksheets (Append1, Append2, ... and so on),
as discussed in the Reference Manual, Append execution of tests, test sequences, and Project
Plans, page 6-168. Each Append worksheet behaves like a Data worksheet. However, its data
cannot be plotted on a separate Graph tab graph, only on the same graph as the Data worksheet
data. For more information about Sheet tabs refer to Understanding and using the Data worksheet
of a Sheet tab.
Each worksheet contains the following controls:
• A data-source identifier.
• Save as button.
Opening a Sheet tab
To open a Sheet tab:
1. In the site navigator, enter the site number where the ITM or UTM was executed, using the
spin button controls (the little arrows at the right).
2. In the project navigator, double-click the name of the ITM or UTM that acquired the data. An
ITM or UTM window appears displaying the definition tab for the selected ITM or UTM.
NOTE If the project plan contains multiple instances of an ITM or UTM under the same
name, each instance generates its own data and has its own unit identification (UID).
Ensure that you select the correct instance of the ITM or UTM.
3. Click the (ITM or UTM) Sheet tab. The Data worksheet of the Sheet tab appears, as well as
tabs that provide access to the corresponding Calc and Settings worksheets.
Figure 2-22 is the Data worksheet of a Sheet tab for the vds-id ITM, showing data for
multiple sweeps. Figure 2-23 is the Data worksheet of a Sheet tab for the vgs-id ITM,
showing formulator calculation results, in addition to test data.
