1-38 Return to Section Topics 4200-900-01 Rev. K / February 2017
Section 1: Getting Started Model 4200-SCS User’s Manual
How to run a basic test
Boot the system and log in
To boot the system and log in:
1. Make sure the power switch is in the O (out) position. The POWER switch is located on the
front panel in lower right-hand corner.
2. Plug the male end of the line cord into a properly grounded AC line power receptacle.
3. Turn on the Model 4200-SCS by pushing in the POWER switch to the I (in) position.
4. When prompted, simultaneously press Ctrl + Alt + Del.
5. At the KIUSER prompt, press ENTER. There is no password for this account.
CAUTION When first starting a KTE-Interactive software tool, you must answer
“YES” to an on-screen license agreement. Answering “No” makes your
system nonfunctional until you reinstall the software.
Open KITE
To start KITE, open the default project, and select the vds-id test:
1. Start KITE by double-clicking the KITE icon on your Microsoft Windows
®
desktop.
2. When KITE starts, the default project will open automatically if it has been set as the default
project. The vds-id test will be opened in the Definition tab (see Figure 1-33).
3. If a different project opens, perform the three steps in Figure 1-34 to open the default
project. The project navigator for the default project is shown in Figure 1-33.
NOTE If the project navigator is not displayed when KITE is started, click the View menu
and select the Project Navigator item. The View menu is at the upper left side of the
KITE window. For more information about the project navigator, refer to the
Reference Manual, Project Navigator, page 6-12.
To open a KITE default project, follow the steps in Figure 1-32.
