4200-900-01 Rev. K / February 2017 Return to Section Topics 2-23
Model 4200-SCS User’s Manual Section 2: Model 4200-SCS Software Environment
Executing an individual test
Selecting a test
An enabled (check marked) ITM or UTM is selected by clicking the test in the project navigator
(see Figure 2-14). The Run Test / Plan button turns green to indicate that the test is enabled
and ready to be run. Also, the selected-test name is displayed in the Test / Plan Indicator box
located above the project navigator.
The test can also be selected by double-clicking it in the project navigator. The double-click action
places the appropriate ITM or UTM window in the KITE workspace. The ITM and UTM definition
tabs show the test configurations.
*1
See Figure 2-4 and Figure 2-5.
NOTE Before executing a test for which data must be labeled with a specific site number,
refer to the Reference Manual, Assigning a site-number label to individual test and
test-sequence data, page 6-30.
Running the test
To run a selected test:
1. Click the green Run Test / Plan button
2.Select Run in the Run menu, or press the F6 keyboard key.
While the test is running, test data is placed the data sheet. In ITMs data is placed in the data
sheet real time as data is being acquired. In UTMs by default, data is not placed in the data sheet
until after the test has finished running.
In the message area of the KITE window, time stamps indicate:
•Start time
• Stop time
• Total execution time
NOTE You can also start a test by pressing the F6 keyboard key. You can abort a test by
clicking the red Abort Test / Plan toolbar button, by selecting Abort in the Run menu,
or by pressing the PAUSE / BREAK keyboard key.
For detailed information about running individual tests, see Reference Manual, Run execution of
individual tests and test sequences, page 6-162.
1. For details about using the ITM and UTM definition tabs, see Reference Manual, Configuring the Project Plan ITMs,
page 6-86, and Configuring the UTMs on page 6-142.
