1-28 Return to Section Topics 4200-900-01 Rev. K / February 2017
Section 1: Getting Started Model 4200-SCS User’s Manual
SCP2 (Oscilloscope)
Keithley Instruments offers two scope cards: 4200-SCP2HR and 4200-SCP2. However, only one
scope card at a time can be used in the 4200-SCS system.
The scope card is a modular, dual-channel, high-speed digital storage oscilloscope (DSO). It uses
a high-speed memory digitizer (DC to 700 MHz) and an embedded digital signal processor (DSP).
The scope card has two input channels to capture and analyze a variety of time-varying signals.
KScope, a soft front-panel software used to view pulse waveforms, is included with the
4200-SCP2HR and 4200-SCP2 (see the “How to Generate Basic Pulses” in Section 5 for details).
KScope provides full control of the DSO and allows export of waveform data that is compatible
with Microsoft
®
Excel
®
. The plug-and-play drivers can be used in most application programming
environments (for example, National Instruments LabVIEW™, Microsoft® Visual Basic
®, and
Microsoft
® Visual C++®).
The primary differences between the two scope cards are ADC resolution and sample rate:
• 4200-SCP2HR: 16-bit resolution, single-channel sampling rate of 400-million samples per
second (400 MS / s)
• 4200-SCP2: 8-bit resolution, single-channel sampling rate of 2.5 billion samples per second
(2.5 GS / s)
Basic pulse characteristics of the two scope cards are listed in Table 1-2. See the supplied ZTEC
User’s Manual for complete specifications of the scope card.
1
NOTE Refer to the Reference Manual, Pulse source-measure connections, page 11-38 for
details about scope card connectors and connections to DUT.
1. The ZTEC User’s Manual is on your Model 4200-SCS Complete Reference Product Information CD.
Table 1-2
Scope card characteristics
Scope card
characteristic
Specifications
4200-SCP2HR (ZT410-50K) 4200-SCP2(ZT450-50K)
Dual channel Simultaneous sampling of both channels Simultaneous sampling of both channels
ADC resolution 16-bit 8-bit
Bandwidth 50 Ω : DC to 250 MHz
1 M Ω : DC to 125 MHz
50 Ω : DC to 1 GHz
1 M Ω : DC to 350 MHz
Maximum input 50 Ω : ±5 V DC
1 M Ω : ±25 V DC
(derated 20 dB / decade above 10 MHz)
50 Ω : ±5 V DC
1 M Ω : ±150 V DC
(derated 20 dB / decade above 1 MHz)
Coupling DC or AC DC or AC
AC coupling 50 Ω : 200 kHz high-pass
1 M Ω : 10 Hz high-pass
50 Ω : 200 kHz high-pass
1 M Ω : 10 Hz high-pass
Probe attenuation 0.9 to 1000:1 0.9 to 1000:1
Analog filter N/A 20 MHz or bypass
Total memory Up to 1 M S per channel
Up to 2 M S per channel (1 channel interleaved)
Up to 1 M S per channel
Up to 2 M S per channel (1 channel interleaved)
Sample (S) rate 10 k S / s to 200 M S / s
10 k S / s to 400 M S / s (1 channel interleaved)
2.5 k S / s to 1.25 G S / s
2.5 k S / s to 2.5 G S / s (1 channel interleaved)
Acquisition time range 250 ns to 3355 s 50 ns to 419 s (2 M sample memory)
