4200-900-01 Rev. K / February 2017 Return to Section Topics 3-119
Model 4200-SCS User’s Manual Section 3: Common Device Characterization Tests
Table 3-29
Interconnect parts for 4200-SCS FLASH package
Table 3-30
Tools supplied with the 4200-SCS FLASH package
NOTE Use the supplied torque wrench to tighten each connection as it is assembled.
Always connect and torque adapter/cable assemblies before attaching the assembly
to the instrument cards.
Pre-torquing eliminates any non-axial stress on the bulkhead connectors on the SMU
or pulse cards, which could cause damage to the cards installed in the 4200-SCS
chassis, requiring repair.
To remove the LEMO triax-to-SMA adapter from a SMU, pull on the knurled silver
portion of the connector to release the latches and permit the adapter to separate
from the SMU connector.
CAUTION Failure to fully disengage the LEMO adapter latches may result in damage
to the adapter and/or the SMU, requiring repair.
The connection instructions below assume a four channel 4200-SCS FLASH
system, consisting of two 4205-PG2 cards (4 pulse channels) as well as four
SMUs, either 4200-SCS SMU or 4210-SMU, with SMU preamps removed (see
Figure 3-83 or Figure 3-84).
To test on-wafer devices, there are various ways to connect the supplied SMA
cables to the probe manipulators. For the direct connect method (see Figure 3-95
and Figure 3-96) or switch method (see Figure 3-97), adapters convert the BNC
cabling to the Triax connector compatible with many types of probe manipulators.
Quantity Description Comment
6 SMA Tee, female – male – female Trigger, combine SMU and PG2
channels
4 LEMO triax to SMA adapter Adapt SMU Force output to SMA for
signal interconnect
4 3 slot male triax to female BNC adapter Convert BNC cabling to Triax for
prober or switch matrix connection
4 SMA male to BNC female adapter Adapt Tee to BNC for cabling from
instrument to probe manipulators
2 4.25 in (10.8) cm white SMA cables Interconnect for triggering
4 8 in (20.3 cm) white SMA cables Interconnect between PG2 and SMU
signals
4 6.6 ft (2 m) white SMA cables
4 5 foot/ 1.5 m BNC cable Connect to probe manipulators
Quantity Description
1 SMA Torque wrench, 8 in-pound, with 5/16 head installed
