Keithley 4200-SCS User Manual

3-118 Return to Section Topics 4200-900-01 Rev. K / February 2017
Section 3: Common Device Characterization Tests Model 4200-SCS User’s Manual
Figure 3-97
Flash Switch connections – characterization, endurance or disturb testing
Figure 3-98
Supplied items for 4200-SCS Flash package
Note: The trigger interconnects are
white SMA cables. Cables from the
instrument to device are BNC coax
for the PG2 channels and Triax for
the SMUs. Use Triax to BNC
adapters if necessary to connect to
probe manipulators .
LEMO Triax Connector
Instrument Connectors
SMA Connector
SMA Tee, male-female-male
Adapters
LEMO Triax -to-SMA Adapter
SMA male to BNC female
Triax female to BNC female
DUT Connections
PG: BL Select /
SMU: BL1
WL1 / Gate
WL2 / Gate
BL2 / Drain
WL1
Bit Line
Select
WL2
WLn
...
Bit Lines
Word Lines
BL1 BL2
BL3
... ...
4205-PG2 #1
Trigger IN
Chan 2
4205-PG2 #2
4.25" (11 cm)
Chan 1
Chan 2
Trigger IN
Trigger OUT
Chan 1
Trigger OUT
4200-SMU/
4210-SMU
Force
78" (2 m) Triax
5' (1.5 m) BNC
4200-SMU/
4210-SMU
Force
4200-SMU/
4210-SMU
Force
4200-SMU/
4210-SMU
Force
5' (1.5 m) BNC
5' (1.5 m) BNC
5' (1.5 m) BNC
78" (2 m) Triax
78" (2 m) Triax
78" (2 m) Triax
Switch Matrix
Card: 8x12
A
B
C
D
E
F
G
H
1
2
3
4
5
6
7
8
9
10
11
12
