:FRANalysis Commands 19
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 453
:FRANalysis:WGEN:VOLTage
(see page 1610)
Command Syntax
:FRANalysis:WGEN:VOLTage
<amplitude>
,[<range>]
<amplitude> ::= amplitude in volts in NR3 format
<range> ::= {F20HZ | F100HZ | F1KHZ | F10KHZ | F100KHZ | F1MHZ
| F10MHZ | F20MHZ}
The :FRANalysis:WGEN:VOLTage command specifies the waveform generator's
output sine wave amplitude.
Use the :WGEN:VOLTage:OFFSet command to specify the offset voltage or DC
level.
You can also specify the amplitude and offset indirectly using the
:WGEN:VOLTage:HIGH and :WGEN:VOLTage:LOW commands. For example, an
amplitude of 5 V and an offset of 1 V is the same as a high-level voltage of 4 V and
a low-level voltage of -1 V.
When the amplitude profile setting is on (:FRANalysis:WGEN:VOLTage:PROFile
ON), the <range> option specifies the initial ramp amplitude at the frequency
setting. Amplitudes ramp between the settings specified for individual frequencies.
Query Syntax
:FRANalysis:WGEN:VOLTage? [<range>]
The :FRANalysis:WGEN:VOLTage? query returns the currently specified waveform
generator amplitude.
When the amplitude profile setting is on (:FRANalysis:WGEN:VOLTage:PROFile
ON), the <range> option specifies the frequency whose initial ramp amplitude is
returned.
Return Format
<amplitude><NL>
<amplitude> ::= amplitude in volts in NR3 format
See Also • ":FRANalysis:WGEN:VOLTage:PROFile" on page 454
• ":FRANalysis:DATA" on page 441
• ":FRANalysis:ENABle" on page 442
• ":FRANalysis:FREQuency:STARt" on page 445
• ":FRANalysis:FREQuency:STOP" on page 446
• ":FRANalysis:PPDecade" on page 447
• ":FRANalysis:RUN" on page 448
• ":FRANalysis:SOURce:INPut" on page 449
• ":FRANalysis:SOURce:OUTPut" on page 450
• ":FRANalysis:WGEN:LOAD" on page 452
