:POWer Commands 26
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 635
:POWer:CLResponse:WGEN:LOAD
(see page 1428)
Command Syntax
:POWer:CLResponse:WGEN:LOAD <impedance>
<impedance> ::= {ONEMeg | FIFTy}
The :POWer:CLResponse:WGEN:LOAD command sets the waveform generator
expected output load impedance.
The output impedance of the Gen Out signal is fixed at 50 ohms. However, the
output load selection lets the waveform generator display the correct amplitude
and offset levels for the expected output load. If the actual load impedance is
different than the selected value, the displayed amplitude and offset levels will be
incorrect.
Query Syntax
:POWer:CLResponse:WGEN:LOAD?
The :POWer:CLResponse:WGEN:LOAD? query returns the waveform generator
expected output load impedance setting.
Return Format
<impedance><NL>
<impedance> ::= {ONEM | FIFT}
See Also • ":POWer:CLResponse" on page 626
• ":POWer:CLResponse:APPLy" on page 627
• ":POWer:CLResponse:DATA" on page 628
• ":POWer:CLResponse:FREQuency:MODE" on page 629
• ":POWer:CLResponse:FREQuency:STARt" on page 630
• ":POWer:CLResponse:FREQuency:STOP" on page 631
• ":POWer:CLResponse:PPDecade" on page 632
• ":POWer:CLResponse:SOURce:INPut" on page 633
• ":POWer:CLResponse:SOURce:OUTPut" on page 634
• ":POWer:CLResponse:WGEN:VOLTage" on page 636
• ":POWer:CLResponse:WGEN:VOLTage:PROFile" on page 637
