:TRIGger:NFC:AEVent
(see page 1428)
Command Syntax
:TRIGger:NFC:AEVent <arm_event>
<arm_event> ::= {NONE | ASReq | AALLreq | AEITher | BSReq | BALLreq
| BEITher | FSReq}
When the ATRigger (Arm & Trigger) trigger event is selected (by
:TRIGger:NFC:TEVent), the :TRIGger:NFC:AEVent command specifies the arm
event. Valid arm event settings depend on the signaling technology selected (by
:TRIGger:NFC:STANdard):
When a trigger event other than ATRigger (Arm & Trigger) is selected, the arm
event is NONE.
Query Syntax
:TRIGger:NFC:AEVent?
The :TRIGger:NFC:AEVent? query returns the specified arm event.
Return Format
<arm_event><NL>
<arm_event> ::= {NONE | ASR | AALL | AEIT | BSR | BALL | BEIT | FSR}
See Also • ":TRIGger:NFC:ATTime" on page 1181
• ":TRIGger:NFC:SOURce" on page 1182
• ":TRIGger:NFC:STANdard" on page 1183
• ":TRIGger:NFC:TEVent" on page 1184
• ":TRIGger:NFC:TIMeout" on page 1186
• ":TRIGger:NFC:TIMeout:ENABle" on page 1187
• ":TRIGger:NFC:TIMeout:TIME" on page 1188
Signaling
Technology
Arm Event Description
NFC-A ASReq SENS_REQ
AALLreq ALL_REQ
AEITher Either the SENS_REQ or ALL_REQ events will arm.
NFC-B BSReq SENSB_REQ
BALLreq ALLB_REQ
BEITher Either the SENSB_REQ or ALLB_REQ events will arm.
NFC-F FSReq SENSF_REQ
