:SBUS<n> Commands 29
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 877
:SBUS<n>:LIN:SIGNal:BAUDrate
(see page 1428)
Command Syntax
:SBUS<n>:LIN:SIGNal:BAUDrate <baudrate>
<baudrate> ::= integer from 2400 to 625000 in 100 b/s increments
The :SBUS<n>:LIN:SIGNal:BAUDrate command sets the standard baud rate of the
LIN signal from 2400 b/s to 625 kb/s in 100 b/s increments. If you enter a baud
rate that is not divisible by 100 b/s, the baud rate is set to the nearest baud rate
divisible by 100 b/s.
Query Syntax
:SBUS<n>:LIN:SIGNal:BAUDrate?
The :SBUS<n>:LIN:SIGNal:BAUDrate? query returns the current LIN baud rate
setting.
Return Format
<baudrate><NL>
<baudrate> ::= integer from 2400 to 625000 in 100 b/s increments
See Also • "Introduction to :TRIGger Commands" on page 1139
• ":TRIGger:MODE" on page 1148
• ":SBUS<n>:LIN:TRIGger" on page 881
• ":SBUS<n>:LIN:SIGNal:DEFinition" on page 1378
• ":SBUS<n>:LIN:SOURce" on page 878
