:DISPlay Commands 15
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 367
:DISPlay:ANNotation<n>:Y1Position
(see page 1428)
Command Syntax
:DISPlay:ANNotation<n>:Y1Position <value>
<value> ::= an integer from 0 to (480 - height of annotation) in NR1 for
mat.
<n> ::= an integer from 1 to 10 in NR1 format.
The :DISPlay:ANNotation<n>:Y1Position command sets the annotation's vertical
Y1 position.
Query Syntax
:DISPlay:ANNotation<n>:Y1Position?
The :DISPlay:ANNotation<n>:Y1Position? query returns the annotation's vertical
Y1 position.
Return Format
<value><NL>
<value> ::= an integer from 0 to (480 - height of annotation) in NR1 for
mat.
See Also • ":DISPlay:ANNotation<n>:X1Position" on page 366
• ":DISPlay:ANNotation<n>" on page 362
• ":DISPlay:ANNotation<n>:COLor" on page 364
• ":DISPlay:ANNotation<n>:BACKground" on page 363
• ":DISPlay:ANNotation<n>:TEXT" on page 365
