:SBUS<n> Commands 31

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 941

:SBUS<n>:FLEXray:TRIGger:FRAMe:ID

(see page 1610)

Command Syntax

:SBUS<n>:FLEXray:TRIGger:FRAMe:ID <frame_id>

<frame_id> ::= {ALL | <frame #>}

<frame #> ::= integer from 1-2047

The :SBUS<n>:FLEXray:TRIGger:FRAMe:ID command sets the FlexRay frame ID to

trigger on. The frame ID setting is only valid when the FlexRay trigger mode is set

to FRAMe.

Query Syntax

:SBUS<n>:FLEXray:TRIGger:FRAMe:ID?

The :SBUS<n>:FLEXray:TRIGger:FRAMe:ID? query returns the current frame ID

setting for the FlexRay frame trigger setup.

Return Format

<frame_id><NL>

<frame_id> ::= {ALL | <frame #>}

<frame #> ::= integer from 1-2047

See Also • "Introduction to :TRIGger Commands" on page 1295

• ":TRIGger:MODE" on page 1308

• ":SBUS<n>:FLEXray:TRIGger" on page 934
