:POWer Commands 28

Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 729

:POWer:CLResponse:WGEN:VOLTage

(see page 1610)

Command Syntax

:POWer:CLResponse:WGEN:VOLTage <amplitude>[,<range>]

<amplitude> ::= amplitude in volts in NR3 format

<range> ::= {F20HZ | F100HZ | F1KHZ | F10KHZ | F100KHZ | F1MHZ

| F10MHZ | F20MHZ}

The :POWer:CLResponse:WGEN:VOLTage command sets the waveform generator

output amplitude(s).

When the waveform generator amplitude profile is enabled (with the

:POWer:CLResponse:WGEN:VOLTage:PROFile command), you can set an initial

ramp amplitude for each frequency range.

Without the <range> parameter, this command sets the waveform generator

output amplitude used when the amplitude profile is disabled.

Query Syntax

:POWer:PSRR:WGEN:VOLTage? [<range>]

The :POWer:CLResponse:WGEN:VOLTage? query returns the waveform generator

output amplitude setting(s).

Return Format

<amplitude> ::= amplitude in volts in NR3 format

See Also • ":POWer:CLResponse" on page 713

• ":POWer:CLResponse:APPLy" on page 714

• ":POWer:CLResponse:DATA" on page 715

• ":POWer:CLResponse:FREQuency:MODE" on page 720

• ":POWer:CLResponse:FREQuency:STARt" on page 722

• ":POWer:CLResponse:FREQuency:STOP" on page 723

• ":POWer:CLResponse:PPDecade" on page 724

• ":POWer:CLResponse:SOURce:INPut" on page 725

• ":POWer:CLResponse:SOURce:OUTPut" on page 726

• ":POWer:CLResponse:WGEN:LOAD" on page 728

• ":POWer:CLResponse:WGEN:VOLTage:PROFile" on page 730
