Keysight Technologies InfiniiVision MSO-X 4154A

Commands Quick Reference 4
Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide 101
:DISPlay:LABList
<binary block> (see
page 372)
:DISPlay:LABList?
(see page 372)
<binary block> ::= an ordered
list of up to 75 labels, each 10
characters maximum, separated by
newline characters
:DISPlay:MENU <menu>
(see page 373)
n/a <menu> ::= {MASK | MEASure |
SEGMented | LISTer | POWer}
:DISPlay:SIDebar
<sidebar> (see
page 374)
n/a <sidebar> ::= {SUMMary | CURSors
| MEASurements | DVM | NAVigate |
CONTrols | EVENts | COUNter}
:DISPlay:PERSistence
<value> (see page 375)
:DISPlay:PERSistence?
(see page 375)
<value> ::= {MINimum | INFinite |
<time>}
<time> ::= seconds in in NR3
format from 100E-3 to 60E0
:DISPlay:VECTors {{0
| OFF} | {1 | ON}}
(see page 376)
:DISPlay:VECTors?
(see page 376)
{0 | 1}
OFF or 0 can only be selected
with the 1 GHz or 1.5 GHz
bandwidth models
Table 12 :DISPlay Commands Summary (continued)
Command Query Options and Query Returns
Table 13 :DVM Commands Summary
Command Query Options and Query Returns
:DVM:ARANge {{0 |
OFF} | {1 | ON}} (see
page 378)
:DVM:ARANge? (see
page 378)
{0 | 1}
n/a :DVM:CURRent? (see
page 379)
<dvm_value> ::= floating-point
number in NR3 format
:DVM:ENABle {{0 |
OFF} | {1 | ON}} (see
page 380)
:DVM:ENABle? (see
page 380)
{0 | 1}
:DVM:MODE <mode> (see
page 381)
:DVM:MODE? (see
page 381)
<dvm_mode> ::= {ACRMs | DC |
DCRMs}
:DVM:SOURce <source>
(see page 382)
:DVM:SOURce? (see
page 382)
<source> ::= {CHANnel<n>}
<n> ::= 1-2 or 1-4 in NR1 format
