Keysight Technologies InfiniiVision MSO-X 4154A

92 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :TER? (see page 261) {0 | 1}
:VIEW <source> (see
page 262)
n/a <source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m> | SBUS{1 |
2} | WMEMory<r>} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> | POD{1 | 2} | BUS{1 |
2} | FUNCtion<m> | MATH<m> |
SBUS{1 | 2} | WMEMory<r>} for MSO
models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
<m> ::= 1 to (# math functions)
in NR1 f?rmat
<r> ::= 1 to (# ref waveforms) in
NR1 format
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
Table 4 :ACQuire Commands Summary
Command Query Options and Query Returns
:ACQuire:COMPlete
<complete> (see
page 265)
:ACQuire:COMPlete?
(see page 265)
<complete> ::= 100; an integer in
NR1 format
:ACQuire:COUNt
<count> (see page 266)
:ACQuire:COUNt? (see
page 266)
<count> ::= an integer from 2 to
65536 in NR1 format
:ACQuire:MODE <mode>
(see page 267)
:ACQuire:MODE? (see
page 267)
<mode> ::= {RTIMe | ETIMe |
SEGMented}
n/a :ACQuire:POINts? (see
page 268)
<# points> ::= an integer in NR1
format
:ACQuire:RSIGnal
<ref_signal_mode>
(see page 269)
:ACQuire:RSIGnal?
(see page 269)
<ref_signal_mode> ::= {OFF | OUT
| IN}
:ACQuire:SEGMented:AN
ALyze (see page 270)
n/a n/a (with Option SGM)
:ACQuire:SEGMented:CO
UNt <count> (see
page 271)
:ACQuire:SEGMented:CO
UNt? (see page 271)
<count> ::= an integer from 2 to
1000 in NR1 format (with Option
SGM)
:ACQuire:SEGMented:IN
Dex <index> (see
page 272)
:ACQuire:SEGMented:IN
Dex? (see page 272)
<index> ::= an integer from 1 to
1000 in NR1 format (with Option
SGM)
