544 Keysight InfiniiVision 4000 X-Series Oscilloscopes Programmer's Guide
22 :MEASure Commands
:MEASure:VMAX
(see page 1428)
Command Syntax
:MEASure:VMAX [<source>]
<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}
<n> ::= 1-2 or 1-4 (# of analog channels) in NR1 format
<m> ::= 1 to (# math functions) in NR1 format
<r> ::= 1 to (# ref waveforms) in NR1 format
The :MEASure:VMAX command installs a screen measurement and starts a
maximum vertical value measurement. If the optional source parameter is
specified, the current source is modified.
Query Syntax
:MEASure:VMAX? [<source>]
The :MEASure:VMAX? query measures and outputs the maximum vertical value
present on the selected waveform.
Return Format
<value><NL>
<value> ::= maximum vertical value of the selected waveform in
NR3 format
See Also • "Introduction to :MEASure Commands" on page 488
• ":MEASure:SOURce" on page 529
• ":MEASure:VMIN" on page 545
• ":MEASure:VPP" on page 546
• ":MEASure:VTOP" on page 550
